NanoPi NEO Air

OS/Raspberry Pi 2017.03.21 23:41 Posted by 파란크리스마스

NanoPi NEO Air

출처 : NanoPi NEO Air

시리얼 연결

  • Debug Port(UART0)

RX | TX | 5v | GND

터미널 연결

기본 로그인 아이디, 패스워드

"root" / "fa"

Wifi 설정

# vi /etc/wpa_supplicant/wpa_supplicant.conf

wpa_supplicant.conf

network={
        ssid="ssid1"
        psk="YourWiFiPassword"
}

network={
        ssid="ssid2"
        psk="YourWiFiPassword"
}

무선랜카드 다시 시작

# ifdown wlan0
Killed old client process
Internet Systems Consortium DHCP Client 4.3.3
Copyright 2004-2015 Internet Systems Consortium.
All rights reserved.
For info, please visit https://www.isc.org/software/dhcp/

Listening on LPF/wlan0/94:a1:a2:94:d1:a0
Sending on   LPF/wlan0/94:a1:a2:94:d1:a0
Sending on   Socket/fallback
DHCPRELEASE on wlan0 to 192.168.0.1 port 67 (xid=0x2f0e629b)
# ifup wlan0
Internet Systems Consortium DHCP Client 4.3.3
Copyright 2004-2015 Internet Systems Consortium.
All rights reserved.
For info, please visit https://www.isc.org/software/dhcp/

Listening on LPF/wlan0/94:a1:a2:94:d1:a0
Sending on   LPF/wlan0/94:a1:a2:94:d1:a0
Sending on   Socket/fallback
DHCPDISCOVER on wlan0 to 255.255.255.255 port 67 interval 3 (xid=0xc921c22e)
DHCPDISCOVER on wlan0 to 255.255.255.255 port 67 interval 6 (xid=0xc921c22e)
DHCPREQUEST of 192.168.0.59 on wlan0 to 255.255.255.255 port 67 (xid=0x2ec221c9)
DHCPOFFER of 192.168.0.59 from 192.168.0.1
DHCPACK of 192.168.0.59 from 192.168.0.1
bound to 192.168.0.59 -- renewal in 2738 seconds.

패키지 업데이트

# apt-get update

Bluetooth

# apt-get install bluetooth bluez obexftp openobex-apps python-gobject ussp-push time bc

How to burn Linux image to eMMC

출처 : How to burn Linux image to eMMC
bpi-copy command

# fdisk -l
Disk /dev/mmcblk0: 7.4 GiB, 7948206080 bytes, 15523840 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0xbac8c0ae

Device         Boot  Start      End  Sectors  Size Id Type
/dev/mmcblk0p1       49152   131071    81920   40M 83 Linux
/dev/mmcblk0p2      131072 15523839 15392768  7.3G 83 Linux


Disk /dev/mmcblk1: 7.3 GiB, 7818182656 bytes, 15269888 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes


Disk /dev/mmcblk1boot1: 4 MiB, 4194304 bytes, 8192 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes


Disk /dev/mmcblk1boot0: 4 MiB, 4194304 bytes, 8192 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes

이미지 복원

이미지 복원이 완료되면 SD 메모리를 제거하고 재부팅

# dd if=nanopi-air-ubuntu-core-qte-sd4g-20170220.img of=/dev/mmcblk1 bs=10MB
389+1 records in
389+1 records out
3899999232 bytes (3.9 GB, 3.6 GiB) copied, 346.862 s, 11.2 MB/s

OpenJDK 1.8 설치

# apt-get install openjdk-8-jdk

JAVA_HOME 환경변수 추가

# vi /etc/profile

내용 추가 export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-armhf

export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-armhf
저작자 표시
신고

Orange PI PC2 GPIO 설치, pi4j

OS/Raspberry Pi 2017.03.17 01:53 Posted by 파란크리스마스

Orange PI PC2 GPIO 설치

출처 : This is a modified WiringPi for OrangePi. We call it WiringOP. Test fo Orangepi pc
OrangePi-PCを使ってみる WiringPiとWiringOP
Orange PI PC 2 GPIO доступ через sysfs

현재 pi4j는 Orange PI PC2 지원하지 않아 수정한 jar를 배포합니다.

pi4j-core.jar

$ git clone https://github.com/kazukioishi/WiringOP.git -b h5
$ cd WiringOP
$ chmod +x ./build
$ sudo ./build
$ gpio -v
gpio version: 2.20
Copyright (c) 2012-2014 Gordon Henderson
This is free software with ABSOLUTELY NO WARRANTY.
For details type: gpio -warranty

Banana Pro Details:
  Type: Banana Pro, Revision: 1.2, Memory: 1024MB, Maker: LeMaker
$ gpio readall
 +-----+-----+----------+------+---+-Orange Pi+---+---+------+---------+-----+--+
 | BCM | wPi |   Name   | Mode | V | Physical | V | Mode | Name     | wPi | BCM |
 +-----+-----+----------+------+---+----++----+---+------+----------+-----+-----+
 |     |     |     3.3v |      |   |  1 || 2  |   |      | 5v       |     |     |
 |  12 |   8 |    SDA.0 | ALT5 | 0 |  3 || 4  |   |      | 5V       |     |     |
 |  11 |   9 |    SCL.0 | ALT5 | 0 |  5 || 6  |   |      | 0v       |     |     |
 |   6 |   7 |   GPIO.7 | ALT3 | 0 |  7 || 8  | 0 | ALT5 | TxD3     | 15  | 13  |
 |     |     |       0v |      |   |  9 || 10 | 0 | ALT5 | RxD3     | 16  | 14  |
 |   1 |   0 |     RxD2 | ALT5 | 0 | 11 || 12 | 0 | ALT3 | GPIO.1   | 1   | 110 |
 |   0 |   2 |     TxD2 | ALT5 | 0 | 13 || 14 |   |      | 0v       |     |     |
 |   3 |   3 |     CTS2 | ALT5 | 0 | 15 || 16 | 0 | ALT3 | GPIO.4   | 4   | 68  |
 |     |     |     3.3v |      |   | 17 || 18 | 0 | ALT3 | GPIO.5   | 5   | 71  |
 |  64 |  12 |     MOSI | ALT4 | 0 | 19 || 20 |   |      | 0v       |     |     |
 |  65 |  13 |     MISO | ALT0 | 0 | 21 || 22 | 0 | ALT5 | RTS2     | 6   | 2   |
 |  66 |  14 |     SCLK | ALT4 | 0 | 23 || 24 | 0 | ALT4 | CE0      | 10  | 67  |
 |     |     |       0v |      |   | 25 || 26 | 0 | ALT3 | GPIO.11  | 11  | 21  |
 |  19 |  30 |    SDA.1 | ALT4 | 0 | 27 || 28 | 0 | ALT4 | SCL.1    | 31  | 18  |
 |   7 |  21 |  GPIO.21 | ALT3 | 0 | 29 || 30 |   |      | 0v       |     |     |
 |   8 |  22 |  GPIO.22 | ALT3 | 0 | 31 || 32 | 0 | ALT5 | RTS1     | 26  | 200 |
 |   9 |  23 |  GPIO.23 | ALT3 | 0 | 33 || 34 |   |      | 0v       |     |     |
 |  10 |  24 |  GPIO.24 | ALT3 | 0 | 35 || 36 | 0 | ALT5 | CTS1     | 27  | 201 |
 |  20 |  25 |  GPIO.25 |  OUT | 1 | 37 || 38 | 0 | ALT5 | TxD1     | 28  | 198 |
 |     |     |       0v |      |   | 39 || 40 | 0 | ALT5 | RxD1     | 29  | 199 |
 +-----+-----+----------+------+---+----++----+---+------+----------+-----+-----+
 | BCM | wPi |   Name   | Mode | V | Physical | V | Mode | Name     | wPi | BCM |
 +-----+-----+----------+------+---+-Orange Pi+---+------+----------+-----+-----+

C언어 샘플 소스

#include <wiringpi.h>

int main()
{
  wiringPiSetup();
  pinMode(7, OUTPUT);
  while(1) {
    digitalWrite(7,HIGH);
    delay(500);
    digitalWrite(7,LOW);
    delay(500);
  }
  return 0;
}

컴파일

$ gcc -Wall -o blink blink.c -lwiringPi -lpthread

실행

$ sudo ./blink
wiringPi: wiringPiSetup called
piboardRev: Hardware string: Hardware   : sun50iw2
Hardware:Hardware       : sun50iw2
piboardRevH3:  3
piboardRev: Hardware string: Hardware   : sun50iw2
Hardware:Hardware       : sun50iw2
piboardRevH3:  3
piboardRev: Hardware string: Hardware   : sun50iw2
Hardware:Hardware       : sun50iw2
piboardId: Revision string: 0000
pinMode,1947,pin:7,mode:1
func:sunxi_set_gpio_mode pin:6, MODE:1 bank:0 index:6 phyaddr:0x1c20800
read reg val: 0x71222222 offset:24
Out mode ready set val: 0x71222222
Out mode set over reg val: 0x71222222
digitalWrite,2270
func:sunxi_digitalWrite pin:6, value:1 bank:0 index:6 phyaddr:0x1c20810
befor write reg val: 0x100040,index:6
HIGH val set over reg val: 0x100040
digitalWrite,2270
func:sunxi_digitalWrite pin:6, value:0 bank:0 index:6 phyaddr:0x1c20810
befor write reg val: 0x100040,index:6
LOW val set over reg val: 0x100000
digitalWrite,2270
func:sunxi_digitalWrite pin:6, value:1 bank:0 index:6 phyaddr:0x1c20810
befor write reg val: 0x100000,index:6
HIGH val set over reg val: 0x100040
digitalWrite,2270
func:sunxi_digitalWrite pin:6, value:0 bank:0 index:6 phyaddr:0x1c20810
befor write reg val: 0x100040,index:6
LOW val set over reg val: 0x100000
digitalWrite,2270
func:sunxi_digitalWrite pin:6, value:1 bank:0 index:6 phyaddr:0x1c20810
befor write reg val: 0x100000,index:6
HIGH val set over reg val: 0x100040

java 샘플 소스

import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.OrangePiPc2GpioProvider;
import com.pi4j.wiringpi.Gpio;

public class Blink {

	public static void main(String[] args) throws InterruptedException {

		GpioFactory.setDefaultProvider(new OrangePiPc2GpioProvider());

		// setup wiring pi
		if (Gpio.wiringPiSetup() == -1) {
			System.out.println(" ==>> GPIO SETUP FAILED");
			return;
		}

		Gpio.pinMode(7, Gpio.OUTPUT);
		while (true) {
			Gpio.digitalWrite(7, Gpio.HIGH);
			Gpio.delay(500);
			Gpio.digitalWrite(7, Gpio.LOW);
			Gpio.delay(500);
		}
	}
}

실행

$ sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar Blink

실행결과

저작자 표시
신고

Orange PI PC2 mjpg-streamer

OS/Raspberry Pi 2017.03.14 23:14 Posted by 파란크리스마스

Orange PI PC2 mjpg-streamer

출처 : 【BPI-M2+】之mjpg-streamer测试和体验- Bananap讨论区- 烽火社区 ...
MJPG-Streamer › Wiki › ubuntuusers.de
라즈베리파이에서 웹캠 mjpg-streamer 따라하기|작성자 서리
mjpg-streamer 웹캠 영상 스트리밍 | Mungrrr

관련 라이브러리 설치

$ sudo apt-get install libjpeg8-dev libv4l-dev subversion
$ sudo apt-get install imagemagick

mjpg-streamer 컴파일 및 설치

출처 : http://www.lavrsen.dk/svn/motion/tags/3.2.9/picture.c

$ svn co https://svn.code.sf.net/p/mjpg-streamer/code/mjpg-streamer mjpg-streamer
$ cd mjpg-streamer
$ make USE_LIBV4L2=true clean all
$ sudo make install
install --mode=755 mjpg_streamer /usr/local/bin
install --mode=644 input_ov5640.so input_gc2035.so input_uvc.so output_file.so output_udp.so output_http.so input_testpicture.so input_file.so /usr/local/lib/
install --mode=755 -d /usr/local/www
install --mode=644 -D www/* /usr/local/www

input_gc2035.so

input_gc2035.tar.gz

mjpg-streamer의 input_uvc.so는 YUV만 지원하고, Orange PI PC2의 카메라인 GC2035는 YUV420코덱만 지원하기 때문에, mjpg-streamer에서 사용 할 수 없습니다.

제가 작업한 GC2035의 YUV420코덱을 지원하는 so 파일을 공개 합니다.
Orange PI PC2의 카메라인 GC2035를 사용해서 mjpg-streamer로 스크리밍 하시려면 첨부한 파일을 사용하세요.

LD_LIBRARY_PATH 경로 추가

$ echo "export LD_LIBRARY_PATH=\$LD_LIBRARY_PATH:/usr/local/lib:/usr/local/lib/mjpg-streamer" | sudo tee -a /etc/profile

mjpg-streamer 실행

$ ./mjpg_streamer -i "./input_gc2035.so -y -n" -o "./output_http.so -w ./www"
MJPG Streamer Version: svn rev: 3:172M
 i: Using V4L2 device.: /dev/video0
 i: Desired Resolution: 640 x 480
 i: Frames Per Second.: 5
 i: Format............: YUV420
 i: JPEG Quality......: 80
 o: www-folder-path...: ./www/
 o: HTTP TCP port.....: 8080
 o: username:password.: disabled
 o: commands..........: enabled

서비스등록

$ sudo vi /etc/init.d/mjpg_streamer

mjpg_streamer 파일 내용

#! /bin/bash
# /etc/init.d/mjpg_streamer.sh
# v0.2 phillips321.co.uk
### BEGIN INIT INFO
# Provides:         mjpg_streamer.sh
# Required-Start:    $network
# Required-Stop:     $network
# Default-Start:     2 3 4 5
# Default-Stop:      0 1 6
# Short-Description: mjpg_streamer for webcam
# Description:       Streams /dev/video0 to http://IP/?action=stream
### END INIT INFO

#
export width=640
export height=480
export fps=24
export SHUTDOWN_WAIT=2
export QUALITY=75

if [ -n "$2" ]; then
  width=$2
fi

if [ -n "$3" ]; then
  height=$3
fi

if [ -n "$4" ]; then
  fps=$4
fi

export LD_MJPG_STREAMER=/usr/local/lib

f_message(){
        echo "[+] $1"
}

mjpg_streamer_pid() {
  echo `ps aux | grep input_gc2035 | grep -v grep | awk '{ print $2 }'`
}

start() {
  pid=$(mjpg_streamer_pid)
  if [ -n "$pid" ]
  then
    echo "mjpg_streamer is already running (pid: $pid)"
  else
    # Start mjpg_streamer
                f_message "Starting mjpg_streamer"
                mjpg_streamer -b -i "$LD_MJPG_STREAMER/input_gc2035.so -r "$width"x"$height" -f $fps -q $QUALITY -y" -o "$LD_MJPG_STREAMER/output_http.so -p 8080 -w /usr/local/www"
                sleep 2
                f_message "mjpg_streamer started"
  fi

  return 0
}

stop() {
  pid=$(mjpg_streamer_pid)
  if [ -n "$pid" ]
  then
    f_message "Stopping mjpg_streamer... (pid: $pid)"
    kill -9 $pid

    let kwait=$SHUTDOWN_WAIT
    let count=0;
    until [ `ps -p $pid | grep -c $pid` = '0' ] || [ $count -gt $kwait ]
    do
      echo -n -e "\nwaiting for processes to exit\n";
      sleep 1
      let count=$count+1;
    done

    if [ $count -gt $kwait ]; then
      echo -n -e "\nkilling processes which didn't stop after $SHUTDOWN_WAIT seconds\n"
      kill -9 $pid
    fi
  else
    echo "mjpg_streamer is not running"
  fi

  return 0
}

# Carry out specific functions when asked to by the system
case "$1" in
        start)
                 start
                 ;;
        stop)
                 stop
                 ;;
        restart)
                 stop
                 sleep 2
                 start
                 ;;
        resolution)
                resolution=`ps axu | grep input_gc2035 | grep -v grep | awk '{ print $16 }'`
                currfps=`ps axu | grep input_gc2035 | grep -v grep | awk '{ print $18 }'`
                if [ -n "$resolution" ];
                then
                        echo "${resolution}"x"$currfps"
                else
                        echo "0x0x0"
                fi
                ;;
        status)
                pid=`ps -A | grep mjpg_streamer | grep -v "grep" | grep -v mjpg_streamer. | awk '{print $1}' | head -n 1`
                if [ -n "$pid" ];
                then
                        f_message "mjpg_streamer is running with pid ${pid}"
                        f_message "mjpg_streamer was started with the following command line"
                        cat /proc/${pid}/cmdline ; echo ""
                else
                        f_message "Could not find mjpg_streamer running"
                fi
                ;;
        *)
                f_message "Usage: $0 {start|stop|status|restart}"
                exit 1
                ;;
esac
exit 0

등록

$ sudo chmod u+x /etc/init.d/mjpg_streamer
$ sudo update-rc.d mjpg_streamer defaults

서비스 실행 및 실행 확인

$ sudo service mjpg_streamer start
$ sudo service mjpg_streamer status
● mjpg_streamer.service - LSB: mjpg_streamer for webcam
   Loaded: loaded (/etc/init.d/mjpg_streamer; bad; vendor preset: enabled)
   Active: active (running) since Wed 2017-03-15 05:05:09 UTC; 4s ago
     Docs: man:systemd-sysv-generator(8)
  Process: 8045 ExecStop=/etc/init.d/mjpg_streamer stop (code=exited, status=0/SUCCESS)
  Process: 8113 ExecStart=/etc/init.d/mjpg_streamer start (code=exited, status=0/SUCCESS)
   CGroup: /system.slice/mjpg_streamer.service
           └─8122 mjpg_streamer -b -i /usr/local/lib/input_gc2035.so -r 640x480 -f 24 -q 75 -y -o /usr/local/lib/output_htt

Mar 15 05:05:07 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: Format............: YUV420
Mar 15 05:05:07 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: JPEG Quality......: 75
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: www-folder-path...: /usr/local/www/
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: HTTP TCP port.....: 8080
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: username:password.: disabled
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: commands..........: enabled
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: starting input plugin /usr/local/lib/input_gc2035.so
Mar 15 05:05:08 Orangepi mjpg_streamer[8122]: MJPG-streamer [8122]: starting output plugin: /usr/local/lib/output_http.so (
Mar 15 05:05:09 Orangepi mjpg_streamer[8113]: [+] mjpg_streamer started
Mar 15 05:05:09 Orangepi systemd[1]: Started LSB: mjpg_streamer for webcam.

실행


저작자 표시
신고

Orange PI PC2 Camera(GC2035), motion

OS/Raspberry Pi 2017.03.14 22:43 Posted by 파란크리스마스

Orange PI PC2 Camera(GC2035), motion

출처 : How to Use Orange Pi Camera in Linux (with Motion)

Camera 모듈 설치

$ sudo vi /etc/modules

내용 추가

gc2035
vfe_v4l2

Camera 설치 확인

$ dmesg | grep gc2035
[   11.157004] [VFE]Find sensor name is "gc2035", i2c address is 78, type is "YUV" !
[   11.157006] [VFE]Sub device register "gc2035" i2c_addr = 0x78 start!
[   11.701914] [VFE]Sub device register "gc2035" is OK!
$ ls /dev/video*
/dev/video0

Camera 정보

$ modinfo gc2035
filename:       /lib/modules/3.10.65/kernel/drivers/media/platform/sunxi-vfe/device/gc2035.ko
license:        GPL
description:    A low-level driver for GalaxyCore gc2035 sensors
author:         raymonxiu
srcversion:     3B1ED5B0A55C98A6E316274
alias:          i2c:gc2035
depends:        vfe_io
intree:         Y
vermagic:       3.10.65 SMP preempt mod_unload modversions aarch64

motion

출처 : How to Use Orange Pi Camera in Linux (with Motion)

$ sudo apt-get install motion
$ sudo motion
[4743584] [NTC] [ALL] conf_load: Processing thread 0 - config file /etc/motion/motion.conf
[4743584] [NTC] [ALL] motion_startup: Motion 3.2.12+git20140228 Started with SDL support
[4743584] [NTC] [ALL] motion_startup: Logging to file (/var/log/motion/motion.log)

motion deamon 실행 수정

$ sudo vi /etc/default/motion

내용 수정

# set to 'yes' to enable the motion daemon
start_motion_daemon=no
저작자 표시
신고

BPI-M2+ / i2c 통신, pi4j, PCA9685

OS/Raspberry Pi 2017.03.12 16:11 Posted by 파란크리스마스

detect I2C chips

출처 : i2cdetect(8): detect I2C chips - Linux man page

$ ls /dev/*i2c*
/dev/i2c-0  /dev/i2c-1
$ i2cdetect -y 0
     0  1  2  3  4  5  6  7  8  9  a  b  c  d  e  f
00:          -- -- -- -- -- -- -- -- -- -- -- -- --
10: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
20: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
40: 40 -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
50: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
70: 70 -- -- -- -- -- -- --

PCA9685 제어

import java.io.IOException;
import java.math.BigDecimal;

import com.pi4j.gpio.extension.pca.PCA9685GpioProvider;
import com.pi4j.gpio.extension.pca.PCA9685Pin;
import com.pi4j.io.gpio.BPIM2PGpioProvider;
import com.pi4j.io.gpio.GpioController;
import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.GpioPinPwmOutput;
import com.pi4j.io.gpio.Pin;
import com.pi4j.io.i2c.I2CBus;
import com.pi4j.io.i2c.I2CFactory;
import com.pi4j.io.i2c.I2CFactory.UnsupportedBusNumberException;

public class PCA9685Gpio {

	public static final int SERVO_DURATION_MIN = 650;
	public static final int SERVO_DURATION_NEUTRAL = 1500;
	public static final int SERVO_DURATION_MAX = 2100;

	private static PCA9685Gpio instance = null;

	private PCA9685GpioProvider gpioProvider = null;

	// sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar PCA9685Gpio

	private PCA9685Gpio() throws IOException, UnsupportedBusNumberException {

		GpioFactory.setDefaultProvider(new BPIM2PGpioProvider());

		System.out.println("<--Pi4J--> PCA9685 PWM Example ... started.");
		// This would theoretically lead into a resolution of 5 microseconds per
		// step:
		// 4096 Steps (12 Bit)
		// T = 4096 * 0.000005s = 0.02048s
		// f = 1 / T = 48.828125
		BigDecimal frequency = new BigDecimal("48.828");
		// Correction factor: actualFreq / targetFreq
		// e.g. measured actual frequency is: 51.69 Hz
		// Calculate correction factor: 51.65 / 48.828 = 1.0578
		// --> To measure actual frequency set frequency without correction
		// factor(or set to 1)
		BigDecimal frequencyCorrectionFactor = new BigDecimal("1.0578");
		// Create custom PCA9685 GPIO provider
		I2CBus bus = I2CFactory.getInstance(I2CBus.BUS_0);
		gpioProvider = new PCA9685GpioProvider(bus, 0x40, frequency, frequencyCorrectionFactor);
		// Define outputs in use for this example
		GpioPinPwmOutput[] myOutputs = provisionPwmOutputs(gpioProvider);
		// Reset outputs
		gpioProvider.reset();
	}

	public static PCA9685Gpio getInstance() throws IOException, UnsupportedBusNumberException {
		if (instance==null) instance = new PCA9685Gpio();
		return instance;
	}

	public void setPwm(Pin pin, int duration) {
		gpioProvider.setPwm(pin, duration);
	}

	public void shutdown() {
		gpioProvider.shutdown();
	}

	private static GpioPinPwmOutput[] provisionPwmOutputs(final PCA9685GpioProvider gpioProvider) {
		GpioController gpio = GpioFactory.getInstance();
		GpioPinPwmOutput myOutputs[] = {
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_00, "Pulse 00"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_01, "Pulse 01"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_02, "Pulse 02"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_03, "Pulse 03"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_04, "Pulse 04"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_05, "Pulse 05"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_06, "Pulse 06"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_07, "Pulse 07"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_08, "Pulse 08"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_09, "Pulse 09"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_10, "Always ON"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_11, "Always OFF"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_12, "Servo pulse MIN"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_13, "Servo pulse NEUTRAL"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_14, "Servo pulse MAX"),
				gpio.provisionPwmOutputPin(gpioProvider, PCA9685Pin.PWM_15, "not used") };
		return myOutputs;
	}

	public static void main(String[] args) throws Exception {

		PCA9685Gpio test = PCA9685Gpio.getInstance();

		test.setPwm(PCA9685Pin.PWM_01, SERVO_DURATION_NEUTRAL);
		Thread.sleep(200);

		for (int i=SERVO_DURATION_MIN; i<=SERVO_DURATION_MAX; i+=30) {
			test.setPwm(PCA9685Pin.PWM_00, i);
			Thread.sleep(200);
		}

		for (int i=SERVO_DURATION_MAX; i>=(int)(SERVO_DURATION_MIN+(SERVO_DURATION_MAX-SERVO_DURATION_MIN)/2); i-=30) {
			test.setPwm(PCA9685Pin.PWM_00, i);
			Thread.sleep(200);
		}

		for (int i=SERVO_DURATION_MIN; i<=SERVO_DURATION_MAX; i+=30) {
			test.setPwm(PCA9685Pin.PWM_01, i);
			Thread.sleep(200);
		}

		for (int i=SERVO_DURATION_MAX-200; i>=(int)(SERVO_DURATION_MIN+(SERVO_DURATION_MAX-SERVO_DURATION_MIN)/2); i-=30) {
			test.setPwm(PCA9685Pin.PWM_01, i);
			Thread.sleep(200);
		}

		test.shutdown();

	}

}

실행

$ sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar PCA9685Gpio
platformId = raspberrypi / label = Raspberry Pi
platformId = bananapi / label = BananaPi
platformId = bananapro / label = BananaPro
platformId = odroid / label = Odroid
platformId = BPI_M2P / label = BPI_M2P
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardId: Revision string: Revision    : 0000
wiringPi: wiringPiSetup called
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardId: Revision string: Revision    : 0000
wiringPiSetup: wiringPiMode = 0
<--Pi4J--> PCA9685 PWM Example ... started.

실행 결과

저작자 표시
신고

BPI-M2+ pi4j

OS/Raspberry Pi 2017.03.12 14:52 Posted by 파란크리스마스

BPI-M2+ pi4j

출처 : The Pi4J Project - Home

현재 pi4j는 BPI-M2+ 지원하지 않아 수정한 jar를 배포합니다.

pi4j-core.jar

GPIO를 이용하여 LED 제어

/*
 * #%L
 * **********************************************************************
 * ORGANIZATION  :  Pi4J
 * PROJECT       :  Pi4J :: Java Examples
 * FILENAME      :  ControlGpioExample.java
 *
 * This file is part of the Pi4J project. More information about
 * this project can be found here:  http://www.pi4j.com/
 * **********************************************************************
 * %%
 * Copyright (C) 2012 - 2016 Pi4J
 * %%
 * This program is free software: you can redistribute it and/or modify
 * it under the terms of the GNU Lesser General Public License as
 * published by the Free Software Foundation, either version 3 of the
 * License, or (at your option) any later version.
 *
 * This program is distributed in the hope that it will be useful,
 * but WITHOUT ANY WARRANTY; without even the implied warranty of
 * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
 * GNU General Lesser Public License for more details.
 *
 * You should have received a copy of the GNU General Lesser Public
 * License along with this program.  If not, see
 * <http://www.gnu.org/licenses/lgpl-3.0.html>.
 * #L%
 */

import com.pi4j.io.gpio.BPIM2PGpioProvider;
import com.pi4j.io.gpio.BPIM2PPin;
import com.pi4j.io.gpio.GpioController;
import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.GpioPinDigitalOutput;
import com.pi4j.io.gpio.PinState;

/**
 * This example code demonstrates how to perform simple state
 * control of a GPIO pin on the Raspberry Pi.
 *
 * @author Robert Savage
 */
public class ControlGpioExample {

    public static void main(String[] args) throws InterruptedException {

        GpioFactory.setDefaultProvider(new BPIM2PGpioProvider());

        System.out.println("<--Pi4J--> GPIO Control Example ... started.");

        // create gpio controller
        final GpioController gpio = GpioFactory.getInstance();

        // provision gpio pin #01 as an output pin and turn on
        final GpioPinDigitalOutput pin = gpio.provisionDigitalOutputPin(BPIM2PPin.GPIO_00, "MyLED", PinState.HIGH);

        // set shutdown state for this pin
        pin.setShutdownOptions(true, PinState.LOW);

        System.out.println("--> GPIO state should be: ON");

        Thread.sleep(5000);

        // turn off gpio pin #01
        pin.low();
        System.out.println("--> GPIO state should be: OFF");

        Thread.sleep(5000);

        // toggle the current state of gpio pin #01 (should turn on)
        pin.toggle();
        System.out.println("--> GPIO state should be: ON");

        Thread.sleep(5000);

        // toggle the current state of gpio pin #01  (should turn off)
        pin.toggle();
        System.out.println("--> GPIO state should be: OFF");

        Thread.sleep(5000);

        // turn on gpio pin #01 for 1 second and then off
        System.out.println("--> GPIO state should be: ON for only 1 second");
        pin.pulse(1000, true); // set second argument to 'true' use a blocking call

        // stop all GPIO activity/threads by shutting down the GPIO controller
        // (this method will forcefully shutdown all GPIO monitoring threads and scheduled tasks)
        gpio.shutdown();

        System.out.println("Exiting ControlGpioExample");
    }
}

실행

$ sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar ControlGpioExample
platformId = raspberrypi / label = Raspberry Pi
platformId = bananapi / label = BananaPi
platformId = bananapro / label = BananaPro
platformId = odroid / label = Odroid
platformId = BPI_M2P / label = BPI_M2P
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardId: Revision string: Revision    : 0000
wiringPi: wiringPiSetup called
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardRev: Hardware string: Hardware   : sun8i
Hardware:Hardware       : sun8i
piboardRev:  3
piboardId: Revision string: Revision    : 0000
wiringPiSetup: wiringPiMode = 0
<--Pi4J--> GPIO Control Example ... started.
pinMode,2272,pin:1,mode:1
func:sunxi_set_pin_mode pin:1, MODE:1 bank:0 index:1 phyaddr:0x1c20800
read reg val: 0x77222212 offset:4
Out mode ready set val: 0x77222212
Out mode set over reg val: 0x77222212
func:sunxi_digitalWrite pin:1, value:1 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8002,index:1
HIGH val set over reg val: 0x8002
--> GPIO state should be: ON
func:sunxi_digitalWrite pin:1, value:0 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8002,index:1
LOW val set over reg val: 0x8000
--> GPIO state should be: OFF
func:sunxi_digitalRead pin:1,bank:0 index:1 phyaddr:0x1c20810
***** read reg val: 0x0,bank:0,index:1,line:1389
func:sunxi_digitalWrite pin:1, value:1 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8000,index:1
HIGH val set over reg val: 0x8002
--> GPIO state should be: ON
func:sunxi_digitalRead pin:1,bank:0 index:1 phyaddr:0x1c20810
***** read reg val: 0x1,bank:0,index:1,line:1389
func:sunxi_digitalWrite pin:1, value:0 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8002,index:1
LOW val set over reg val: 0x8000
--> GPIO state should be: OFF
--> GPIO state should be: ON for only 1 second
func:sunxi_digitalWrite pin:1, value:1 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8000,index:1
HIGH val set over reg val: 0x8002
func:sunxi_digitalWrite pin:1, value:0 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8002,index:1
LOW val set over reg val: 0x8000
func:sunxi_digitalWrite pin:1, value:0 bank:0 index:1 phyaddr:0x1c20810
befor write reg val: 0x8000,index:1
LOW val set over reg val: 0x8000
Exiting ControlGpioExample

실행 결과

저작자 표시
신고

MySQL 5.7.17 - 수동설치

Database 2017.03.04 19:40 Posted by 파란크리스마스

MySQL 5.7.17 - 수동설치

출처 : 취향창고 :: [윈도우10]mysql 5.7.10 수동 설치기

환경파일 생성(mysql.ini)

[mysqld]
# port
# port=3306
# set basedir to your installation path
basedir=C:/mysql/mysql-5.7.17-winx64
# set datadir to the location of your data directory
datadir=C:/mysql/mysql-5.7.17-winx64/data

character-set-server=utf8
collation-server=utf8_general_ci

#default-storage-engine = InnoDB
#default-table-type = InnoDB
transaction-isolation = READ-COMMITTED

[mysql]
no-auto-rehash
default-character-set=utf8

[client]
default-character-set=utf8

초기화

bin\mysqld --initialize

root 계정 암호 초기화

권한 없이 mysql 서버 실행

bin\mysqld --skip-grant-tables

root 계정 암호 설정

C:\mysql\mysql-5.7.17-winx64>bin\mysql -u root -p
Enter password:
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 3
Server version: 5.7.17 MySQL Community Server (GPL)

Copyright (c) 2000, 2016, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> use mysql
Database changed
mysql> update user set authentication_string = password('sql') where user = 'root';
Query OK, 1 row affected, 1 warning (0.00 sec)
Rows matched: 1  Changed: 1  Warnings: 1

mysql> flush privileges;
Query OK, 0 rows affected (0.00 sec)

mysql> quit
Bye

localhost용 root 계정 등록

C:\mysql\mysql-5.7.17-winx64>bin\mysql -u root -p
Enter password: ***
Welcome to the MySQL monitor.  Commands end with ; or \g.
Your MySQL connection id is 9
Server version: 5.7.17

Copyright (c) 2000, 2016, Oracle and/or its affiliates. All rights reserved.

Oracle is a registered trademark of Oracle Corporation and/or its
affiliates. Other names may be trademarks of their respective
owners.

Type 'help;' or '\h' for help. Type '\c' to clear the current input statement.

mysql> alter user 'root'@'localhost' identified by 'sqldba';
Query OK, 0 rows affected (0.00 sec)

mysql> flush privileges;
Query OK, 0 rows affected (0.01 sec)

mysql> quit
Bye

mysql 서비스 등록

bin\mysqld.exe --install "MySQL 5.7.17" --defaults-file=C:\mysql\mysql-5.7.17-winx64\mysql.ini

mysql 서비스 삭제

bin\mysqld.exe --remove "MySQL 5.7.17"
저작자 표시
신고

POI 라이브러리 사용 Excel Loader 구현

Programming/Java 2017.02.28 22:18 Posted by 파란크리스마스

ExcelUtils

package com.intel4.poi;

import java.io.IOException;
import java.io.InputStream;

import org.apache.poi.hssf.usermodel.HSSFWorkbook;
import org.apache.poi.ss.usermodel.Cell;
import org.apache.poi.ss.usermodel.Row;
import org.apache.poi.ss.usermodel.Workbook;
import org.apache.poi.xssf.usermodel.XSSFWorkbook;

public class ExcelUtils {

	// 엑셀로드
	public static Workbook loalDocument(String filename,InputStream is) throws IOException {
		if (filename.endsWith(".xlsx")) {
			return new XSSFWorkbook(is);
		}
		else   if (filename.endsWith("xls")) {
			return new HSSFWorkbook(is);
		}
		else {
			throw new IllegalArgumentException("Unsupported extension for resource [" + filename + "]");
		}
	}

	// 문자열 반환
	public static String getStringValue(Row row, int col) {

		if (row == null) return null;
		if (row.getCell(col) == null) return null;

		String value = "";
		if (row.getCell(col).getCellType()==Cell.CELL_TYPE_NUMERIC) {
			double doubleValue = row.getCell(col).getNumericCellValue();
			if ((doubleValue == Math.floor(doubleValue)) && !Double.isInfinite(doubleValue)) {
				value = String.valueOf((int)row.getCell(col).getNumericCellValue());
			} else {
				value = String.valueOf(row.getCell(col).getNumericCellValue());
			}
			//System.out.println("doubleValue = " + doubleValue + "/" + value);
		} else if (row.getCell(col).getCellType()==Cell.CELL_TYPE_STRING) {
			try {
				value = row.getCell(col).getStringCellValue();
			} catch (Exception e) {
				e.printStackTrace();
			}
		}
		return value;
	}

	// int 값 반환
	public static int getIntegerValue(Row row, int col) {

		if (row == null) return 0;
		if (row.getCell(col) == null) return 0;

		int value = 0;
		if (row.getCell(col).getCellType()==Cell.CELL_TYPE_NUMERIC) {
			double doubleValue = row.getCell(col).getNumericCellValue();
			if ((doubleValue == Math.floor(doubleValue)) && !Double.isInfinite(doubleValue)) {
				value = (int)row.getCell(col).getNumericCellValue();
			} else {
				value = (int)row.getCell(col).getNumericCellValue();
			}
			//System.out.println("doubleValue = " + doubleValue + "/" + value);
		} else if (row.getCell(col).getCellType()==Cell.CELL_TYPE_STRING) {
			try {
				String stringValue = row.getCell(col).getStringCellValue();
				if (stringValue==null || stringValue.trim().length()==0 || !isNumeric(stringValue)) return 0;
				value = Integer.parseInt(row.getCell(col).getStringCellValue());
			} catch (Exception e) {
				e.printStackTrace();
			}
		}
		return value;
	}

	// 숫자여부 판단
	public static boolean isNumeric(String str) {
	  return str.matches("-?\\d+(\\.\\d+)?");  //match a number with optional '-' and decimal.
	}

}

ExcelLoader

package com.intel4.poi;

import java.io.File;
import java.io.FileInputStream;

import org.apache.poi.ss.usermodel.Row;
import org.apache.poi.ss.usermodel.Sheet;
import org.apache.poi.ss.usermodel.Workbook;

public class ExcelLoader {

	public static void main(String[] args) {
		ExcelLoader loader = new ExcelLoader();
		loader.load("WebContent\\sample.xlsx");
	}

	public void load(String filename) {
		int start_row = 1;

		FileInputStream inputStream = null;
		try {
			inputStream = new FileInputStream(new File(filename));
			Workbook workbook = ExcelUtils.loalDocument(filename, inputStream);

			// Excel 시트
			Sheet sheet = workbook.getSheetAt(0);

			// 해당 시트의 마지막 Row까지 반복
			for (int row_index=start_row; row_index<=sheet.getLastRowNum(); row_index++) {
				// Excel Row
				Row row = sheet.getRow(row_index);
				// row가 null인 경우 다음 row로...
				if (row == null) continue;

				int basic_seq = ExcelUtils.getIntegerValue(row, 0);
				int seq = ExcelUtils.getIntegerValue(row, 1);
				int problem = ExcelUtils.getIntegerValue(row, 2);
				String answer = ExcelUtils.getStringValue(row, 3);
				int hint  = ExcelUtils.getIntegerValue(row, 4);
				String subject1 = ExcelUtils.getStringValue(row, 5);
				String subject2 = ExcelUtils.getStringValue(row, 6);
				int level = ExcelUtils.getIntegerValue(row, 7);

				System.out.println(basic_seq + "/" + seq + "/" + problem +"/"+ answer + "/" + hint + "/" + subject1 + "/" + subject2 + "/" +  level);
			}

		} catch (Exception e) {
			e.printStackTrace();
		} finally {
			if (inputStream!=null) {
				try {
					inputStream.close();
				} catch (Exception e) {
					e.printStackTrace();
				}
			}
		}

	}

}
저작자 표시
신고

Banana PI - BPI-M2+

OS/Raspberry Pi 2017.02.26 22:23 Posted by 파란크리스마스

Banana PI - BPI-M2+

출처 : BPI-M2+
【BPI-M2+】之mjpg-streamer测试和体验- Bananap讨论区- 烽火社区 ...
http://forum.banana-pi.org/c/Banana-pi-BPI-M2

SD 확장

SD 확장전 용량확인

$ df -l
Filesystem     1K-blocks    Used Available Use% Mounted on
/dev/root        7156088 4680932   2111636  69% /
devtmpfs          380800       0    380800   0% /dev
tmpfs             512036     800    511236   1% /dev/shm
tmpfs             512036   20248    491788   4% /run
tmpfs               5120       4      5116   1% /run/lock
tmpfs             512036       0    512036   0% /sys/fs/cgroup
/dev/mmcblk0p1    261868  213188     48680  82% /boot
tmpfs             102408      36    102372   1% /run/user/1000

SD FDisk

pi@bpi-iot-ros-ai:~$ sudo fdisk /dev/mmcblk0

Welcome to fdisk (util-linux 2.27.1).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.


Command (m for help): p
Disk /dev/mmcblk0: 14.7 GiB, 15811477504 bytes, 30881792 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x0006c94a

Device         Boot  Start      End  Sectors  Size Id Type
/dev/mmcblk0p1 *    204800   729087   524288  256M  c W95 FAT32 (LBA)
/dev/mmcblk0p2      729088 15269887 14540800    7G 83 Linux

Command (m for help): d
Partition number (1,2, default 2): 2

Partition 2 has been deleted.

Command (m for help): n
Partition type
   p   primary (1 primary, 0 extended, 3 free)
   e   extended (container for logical partitions)
Select (default p): p
Partition number (2-4, default 2): 2
First sector (2048-30881791, default 2048): 729088
Last sector, +sectors or +size{K,M,G,T,P} (729088-30881791, default 30881791):

Created a new partition 2 of type 'Linux' and of size 14.4 GiB.

Command (m for help): w
The partition table has been altered.
Calling ioctl() to re-read partition table.
Re-reading the partition table failed.: Device or resource busy

The kernel still uses the old table. The new table will be used at the next reboot or after you run partprobe(8) or kpartx(8).

pi@bpi-iot-ros-ai:~$ sudo shutdown -r now

SD 확장

$ sudo resize2fs /dev/mmcblk0p2
resize2fs 1.42.13 (17-May-2015)
Filesystem at /dev/mmcblk0p2 is mounted on /; on-line resizing required
old_desc_blocks = 1, new_desc_blocks = 1
The filesystem on /dev/mmcblk0p2 is now 3769088 (4k) blocks long.

SD 확장 확인

$ df -l
Filesystem     1K-blocks    Used Available Use% Mounted on
/dev/root       14839632 4653484   9513188  33% /
devtmpfs          380800       0    380800   0% /dev
tmpfs             512036     316    511720   1% /dev/shm
tmpfs             512036    7456    504580   2% /run
tmpfs               5120       4      5116   1% /run/lock
tmpfs             512036       0    512036   0% /sys/fs/cgroup
/dev/mmcblk0p1    261868  213188     48680  82% /boot
tmpfs             102408      28    102380   1% /run/user/1000

How to burn Linux image to eMMC

출처 : How to burn Linux image to eMMC
bpi-copy command

root@bpi-iot-ros-ai:~# uname -a
Linux bpi-iot-ros-ai 3.4.112-sun8i #2 SMP PREEMPT Mon May 30 20:34:33 CST 2016 armv7l armv7l armv7l GNU/Linux
root@bpi-iot-ros-ai:~# fdisk -l
Disk /dev/mmcblk0: 14.7 GiB, 15811477504 bytes, 30881792 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x0006c94a

Device         Boot  Start      End  Sectors  Size Id Type
/dev/mmcblk0p1 *    204800   729087   524288  256M  c W95 FAT32 (LBA)
/dev/mmcblk0p2      729088 30881791 30152704 14.4G 83 Linux


Disk /dev/mmcblk1: 7.3 GiB, 7818182656 bytes, 15269888 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x00000000


Disk /dev/mmcblk1boot1: 4 MiB, 4194304 bytes, 8192 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes


Disk /dev/mmcblk1boot0: 4 MiB, 4194304 bytes, 8192 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes

이미지 복원

이미지 복원이 완료되면 SD 메모리를 제거하고 재부팅

$ sudo dd if=2016-07-21-ubuntu-mate-16.04-desktop-armhf-raspberry-pi-bpi-m2p-sd-emmc.img of=/dev/mmcblk1 bs=10MB
781+1 records in
781+1 records out
7818182656 bytes (7.8 GB, 7.3 GiB) copied, 1023.46 s, 7.6 MB/s

eMMC 부팅(SD동시 사용 - 적용실패)

출처 : Banana Pi M2+ with system on emmc, data on sd card - Allwinner H2/H3
Boot from eMMC with blank SD in slot (BPI-M3)

$ cat /etc/fstab
proc            /proc           proc    defaults          0       0
/dev/mmcblk0p2  /               ext4   defaults,noatime  0       1
/dev/mmcblk0p1  /boot/          vfat    defaults          0       2
$ lsblk
NAME         MAJ:MIN RM  SIZE RO TYPE MOUNTPOINT
mmcblk0boot0 179:16   0    4M  1 disk
mmcblk0boot1 179:32   0    4M  1 disk
mmcblk0      179:0    0  7.3G  0 disk
쒋mmcblk0p1  179:1    0  256M  0 part /boot
붴mmcblk0p2  179:2    0    7G  0 part /
$ cat /boot/boot.cmd
#setenv device mmc
#setenv partition 0:1
setenv bpi bananapi
setenv board bpi-m64
setenv chip a64
setenv service linux
setenv kernel Image
setenv initrd initrd.img
setenv dtb pine64-plus.dtb

setenv bootargs "console=ttyS0,115200n8 no_console_suspend earlycon=uart,mmio32,0x01c28000 mac_addr=${ethaddr} board=${board} root=${root} rootwait panic=10 consoleblank=0 enforcing=0 loglevel=2"


setenv fdt_filename "${bpi}/${board}/${service}/${dtb}"
setenv kernel_filename "${bpi}/${board}/${service}/${kernel}"
setenv initrd_filename "${bpi}/${board}/${service}/${initrd}"

run load_dtb load_kernel load_initrd boot_kernel

## Recompile with:
## mkimage -C none -A arm -T script -d /boot/boot.cmd /boot/boot.scr
## mkimage -C none -A arm -T script -d boot.cmd boot.scr

generate boot.src

$ sudo mkimage -C none -A arm -T script -d /boot/boot.cmd /boot/boot.scr
Image Name:
Created:      Sun Feb  26 11:55:34 2017
Image Type:   ARM Linux Script (uncompressed)
Data Size:    805 Bytes = 0.79 kB = 0.00 MB
Load Address: 00000000
Entry Point:  00000000
Contents:
   Image 0: 797 Bytes = 0.78 kB = 0.00 MB
$ sudo shutdown -r now

GPIO사용 (BPI-WiringPi)

출처 : Supports BananaPi BPI -M1 / M1Plus / M2 / M2P / M3

기존 설치된 wiringpi 삭제

$ sudo apt-get remove wiringpi
$ sudo apt autoremove

wiringpi 설치

$ git clone https://github.com/BPI-SINOVOIP/BPI-WiringPi.git -b BPI_M2P
$ cd BPI-WiringPi
$ chmod +x ./build
$ sudo ./build

GPIO 확인

$ gpio -v
gpio version: 2.26
Copyright (c) 2012-2015 Gordon Henderson
This is free software with ABSOLUTELY NO WARRANTY.
For details type: gpio -warranty

Banana Pi Details:
  Type: Model BM, Revision: 1.2, Memory: 1024MB, Maker: BPI
$ gpio readall
 +-----+-----+---------+------+---+---Pi ---+---+------+---------+-----+-----+
 | CPU | wPi |    Name   | Mode | V | Physical | V | Mode |   Name    | wPi | CPU |
 +-----+-----+-----------+------+---+----++----+---+------+-----------+-----+-----+
 |     |     |      3.3v |      |   |  1 || 2  |   |      | 5v        |     |     |
 |  12 |   8 |     SDA.1 | ALT5 | 0 |  3 || 4  |   |      | 5V        |     |     |
 |  11 |   9 |     SCL.1 | ALT5 | 0 |  5 || 6  |   |      | GND       |     |     |
 |   6 |   7 |      PWM1 | ALT3 | 0 |  7 || 8  | 0 | ALT4 | UART3-TX  | 15  | 13  |
 |     |     |       GND |      |   |  9 || 10 | 0 | ALT4 | UART3-RX  | 16  | 14  |
 |   1 |   0 |  UART2-RX | ALT5 | 0 | 11 || 12 | 0 | OUT  | UART3-CTS | 1   | 16  |
 |   0 |   2 |  UART2-TX | ALT5 | 0 | 13 || 14 |   |      | GND       |     |     |
 |   3 |   3 | UART2-CTS | ALT5 | 0 | 15 || 16 | 1 | ALT4 | UART3-RTS | 4   | 15  |
 |     |     |      3.3v |      |   | 17 || 18 | 0 | ALT3 | GPIO.PC04 | 5   | 68  |
 |  64 |  12 | SPI0_MOSI | ALT4 | 0 | 19 || 20 |   |      | GND       |     |     |
 |  65 |  13 | SPI0_MISO | ALT4 | 0 | 21 || 22 | 0 | ALT5 | UART2-RTS | 6   | 2   |
 |  66 |  14 |  SPI0_CLK | ALT4 | 0 | 23 || 24 | 0 | ALT4 | SPI0-CS   | 10  | 67  |
 |     |     |       GND |      |   | 25 || 26 | 0 | ALT3 | GPIO.PL07 | 11  | 71  |
 |  19 |  30 |     SDA.0 | ALT4 | 0 | 27 || 28 | 0 | ALT4 | SCL.0     | 31  | 18  |
 |   7 |  21 | GPIO.PA07 | ALT3 | 0 | 29 || 30 |   |      | GND       |     |     |
 |   8 |  22 | GPIO.PA08 | ALT3 | 0 | 31 || 32 | 0 | ALT3 | GPIO.PL02 | 26  | 354 |
 |   9 |  23 | GPIO.PA09 | ALT3 | 0 | 33 || 34 |   |      | GND       |     |     |
 |  10 |  24 | GPIO.PA10 | ALT3 | 0 | 35 || 36 | 0 | ALT3 | GPIO.PL04 | 27  | 356 |
 |  17 |  25 | SPDIF-OUT | ALT3 | 0 | 37 || 38 | 0 | ALT3 | GPIO.PA21 | 28  | 21  |
 |     |     |       GND |      |   | 39 || 40 | 0 | ALT3 | GPIO.PA20 | 29  | 20  |
 +-----+-----+-----------+------+---+----++----+---+------+-----------+-----+-----+
 | CPU | wPi |    Name   | Mode | V | Physical | V | Mode |   Name    | wPi | CPU |
 +-----+-----+---------+------+---+---Pi ---+---+------+---------+-----+-----+

detect I2C chips

출처 : i2cdetect(8): detect I2C chips - Linux man page

$ ls /dev/*i2c*
/dev/i2c-0  /dev/i2c-1
$ i2cdetect -y 0
     0  1  2  3  4  5  6  7  8  9  a  b  c  d  e  f
00:          -- -- -- -- -- -- -- -- -- -- -- -- --
10: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
20: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
40: 40 -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
50: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
70: 70 -- -- -- -- -- -- --

jdk1.8 설치

출처 : 우분투(Ubuntu) Oracle(Sun) Java JDK 설치 - 사르기스

OpenJDK 제거

$ sudo apt-get purge openjdk*

repository 추가

$ sudo add-apt-repository ppa:webupd8team/java

repository index 업데이트

$ sudo apt-get update

JDK 설치

$ sudo apt-get install oracle-java8-installer

JAVA_HOME 환경변수 추가

$ sudo vi /etc/profile

내용 추가 export JAVA_HOME=/usr/lib/jvm/java-8-oracle

export JAVA_HOME=/usr/lib/jvm/java-8-oracle

pi4j

촐처 : Java I/O library for Raspberry Pi (GPIO, I2C, SPI, UART) http://www.pi4j.com
BUILDING AN EXECUTABLE PI4J JAR

$ sudo apt install maven
$ git clone https://github.com/Pi4J/pi4j.git
$ cd pi4j/pi4j-native
$ mvn package

pi4j pwm 오류

촐처 : How to: banana pi BPI-M3 install BPI-WiringPi - Linux - banana pi ...

PWM 관련 오류가 있어 수정해 보려고 했으나 포기

val pwmWrite 0 <= X <= 1024
Or you can set new range by yourself by pwmSetRange(range
저작자 표시
신고

Spring - Drag & Drop 파일 업로드

Programming/Java 2017.02.26 18:42 Posted by 파란크리스마스

Spring - Drag & Drop 파일 업로드

출처 : Husk's repository :: 드래그 앤 드롭 파일 업로드 스프링 예제

관련 라이브러리 추가

commons-io-2.4.jar
commons-fileupload-1.3.jar

WebContent\WEB-INF\iot-servlet.xml

	<!-- ========================= Multipart Form-Data Resolver ========================= -->
	<bean id="multipartResolver" class="org.springframework.web.multipart.commons.CommonsMultipartResolver">
		<!-- max upload size in bytes -->
		<property name="maxUploadSize" value="20971520" /> <!-- 20MB -->
		<!-- max size of file in memory (in bytes) -->
		<property name="maxInMemorySize" value="1048576" /> <!-- 1MB -->
	</bean>

업로드 jsp (WebContent\WEB-INF\jsp\dragdrop\fileUpload.jsp)

<%@ page language="java" contentType="text/html; charset=UTF-8" pageEncoding="UTF-8"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c" %>
<%@ page session="false" %>
<html>
    <head>
        <title>Test</title>
        <script type="text/javascript" src="http://code.jquery.com/jquery-1.11.3.js"></script>
        <style>
            .dragAndDropDiv {
                border: 2px dashed #92AAB0;
                width: 650px;
                height: 200px;
                color: #92AAB0;
                text-align: center;
                vertical-align: middle;
                padding: 10px 0px 10px 10px;
                font-size:200%;
                display: table-cell;
            }
            .progressBar {
                width: 200px;
                height: 22px;
                border: 1px solid #ddd;
                border-radius: 5px;
                overflow: hidden;
                display:inline-block;
                margin:0px 10px 5px 5px;
                vertical-align:top;
            }

            .progressBar div {
                height: 100%;
                color: #fff;
                text-align: right;
                line-height: 22px; /* same as #progressBar height if we want text middle aligned */
                width: 0;
                background-color: #0ba1b5; border-radius: 3px;
            }
            .statusbar{
                border-top:1px solid #A9CCD1;
                min-height:25px;
                width:99%;
                padding:10px 10px 0px 10px;
                vertical-align:top;
            }
            .statusbar:nth-child(odd){
                background:#EBEFF0;
            }
            .filename{
                display:inline-block;
                vertical-align:top;
                width:250px;
            }
            .filesize{
                display:inline-block;
                vertical-align:top;
                color:#30693D;
                width:100px;
                margin-left:10px;
                margin-right:5px;
            }
            .abort{
                background-color:#A8352F;
                -moz-border-radius:4px;
                -webkit-border-radius:4px;
                border-radius:4px;display:inline-block;
                color:#fff;
                font-family:arial;font-size:13px;font-weight:normal;
                padding:4px 15px;
                cursor:pointer;
                vertical-align:top
            }
        </style>
        <script type="text/javascript">
            $(document).ready(function(){
                var objDragAndDrop = $(".dragAndDropDiv");

                $(document).on("dragenter",".dragAndDropDiv",function(e){
                    e.stopPropagation();
                    e.preventDefault();
                    $(this).css('border', '2px solid #0B85A1');
                });
                $(document).on("dragover",".dragAndDropDiv",function(e){
                    e.stopPropagation();
                    e.preventDefault();
                });
                $(document).on("drop",".dragAndDropDiv",function(e){

                    $(this).css('border', '2px dotted #0B85A1');
                    e.preventDefault();
                    var files = e.originalEvent.dataTransfer.files;

                    handleFileUpload(files,objDragAndDrop);
                });

                $(document).on('dragenter', function (e){
                    e.stopPropagation();
                    e.preventDefault();
                });
                $(document).on('dragover', function (e){
                  e.stopPropagation();
                  e.preventDefault();
                  objDragAndDrop.css('border', '2px dotted #0B85A1');
                });
                $(document).on('drop', function (e){
                    e.stopPropagation();
                    e.preventDefault();
                });

                function handleFileUpload(files,obj)
                {
                   for (var i = 0; i < files.length; i++)
                   {
                        var fd = new FormData();
                        fd.append('file', files[i]);

                        var status = new createStatusbar(obj); //Using this we can set progress.
                        status.setFileNameSize(files[i].name,files[i].size);
                        sendFileToServer(fd,status);

                   }
                }

                var rowCount=0;
                function createStatusbar(obj){

                    rowCount++;
                    var row="odd";
                    if(rowCount %2 ==0) row ="even";
                    this.statusbar = $("<div class='statusbar "+row+"'></div>");
                    this.filename = $("<div class='filename'></div>").appendTo(this.statusbar);
                    this.size = $("<div class='filesize'></div>").appendTo(this.statusbar);
                    this.progressBar = $("<div class='progressBar'><div></div></div>").appendTo(this.statusbar);
                    this.abort = $("<div class='abort'>중지</div>").appendTo(this.statusbar);

                    obj.after(this.statusbar);

                    this.setFileNameSize = function(name,size){
                        var sizeStr="";
                        var sizeKB = size/1024;
                        if(parseInt(sizeKB) > 1024){
                            var sizeMB = sizeKB/1024;
                            sizeStr = sizeMB.toFixed(2)+" MB";
                        }else{
                            sizeStr = sizeKB.toFixed(2)+" KB";
                        }

                        this.filename.html(name);
                        this.size.html(sizeStr);
                    }

                    this.setProgress = function(progress){
                        var progressBarWidth =progress*this.progressBar.width()/ 100;
                        this.progressBar.find('div').animate({ width: progressBarWidth }, 10).html(progress + "% ");
                        if(parseInt(progress) >= 100)
                        {
                            this.abort.hide();
                        }
                    }

                    this.setAbort = function(jqxhr){
                        var sb = this.statusbar;
                        this.abort.click(function()
                        {
                            jqxhr.abort();
                            sb.hide();
                        });
                    }
                }

                function sendFileToServer(formData,status)
                {
                    var uploadURL = "<c:url value="/dragdrop/fileUpload/post.iot"/>"; //Upload URL
                    var extraData ={}; //Extra Data.
                    var jqXHR=$.ajax({
                            xhr: function() {
                            var xhrobj = $.ajaxSettings.xhr();
                            if (xhrobj.upload) {
                                    xhrobj.upload.addEventListener('progress', function(event) {
                                        var percent = 0;
                                        var position = event.loaded || event.position;
                                        var total = event.total;
                                        if (event.lengthComputable) {
                                            percent = Math.ceil(position / total * 100);
                                        }
                                        //Set progress
                                        status.setProgress(percent);
                                    }, false);
                                }
                            return xhrobj;
                        },
                        url: uploadURL,
                        type: "POST",
                        contentType:false,
                        processData: false,
                        cache: false,
                        data: formData,
                        success: function(data){
                            status.setProgress(100);

                            //$("#status1").append("File upload Done<br>");
                        }
                    });

                    status.setAbort(jqXHR);
                }

            });
        </script>
    </head>

    <body>
        <div id="fileUpload" class="dragAndDropDiv">Drag & Drop Files Here</div>
    </body>
</html>

Controller

package com.iot.controller;

import java.io.File;
import java.util.Iterator;

import org.springframework.stereotype.Controller;
import org.springframework.ui.Model;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestMethod;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.multipart.MultipartFile;
import org.springframework.web.multipart.MultipartHttpServletRequest;

/**
 * Handles requests for the application home page.
 */

@Controller
public class FileUploadDragDropController {

	@RequestMapping(value = "/dragdrop/fileUpload.iot", method = RequestMethod.GET)
	public String dragAndDrop(Model model) {
		return "/dragdrop/fileUpload";
	}

	@RequestMapping(value = "/dragdrop/fileUpload/post.iot") // ajax에서 호출하는 부분
	@ResponseBody
	public String upload(MultipartHttpServletRequest multipartRequest) { // Multipart로
																																				// 받는다.

		Iterator<String> itr = multipartRequest.getFileNames();

		String filePath = "C:/test"; // 설정파일로 뺀다.

		while (itr.hasNext()) { // 받은 파일들을 모두 돌린다.

			/*
			 * 기존 주석처리 MultipartFile mpf = multipartRequest.getFile(itr.next());
			 * String originFileName = mpf.getOriginalFilename(); System.out.println(
			 * "FILE_INFO: "+originFileName); //받은 파일 리스트 출력'
			 */

			MultipartFile mpf = multipartRequest.getFile(itr.next());

			String originalFilename = mpf.getOriginalFilename(); // 파일명

			String fileFullPath = filePath + "/" + originalFilename; // 파일 전체 경로

			try {
				// 파일 저장
				mpf.transferTo(new File(fileFullPath)); // 파일저장 실제로는 service에서 처리

				System.out.println("originalFilename => " + originalFilename);
				System.out.println("fileFullPath => " + fileFullPath);

			} catch (Exception e) {
				System.out.println("postTempFile_ERROR======>" + fileFullPath);
				e.printStackTrace();
			}

		}

		return "success";
	}

}

업로드된 폴더 웹에서 접근하기

Tomcat 설정파일 server.xml에 <Context docBase="C:/test" path="/test" reloadable="true"/> 를 Host 테그 전에 추가

        <Context docBase="C:/test" path="/test" reloadable="true"/>
      </Host>
    </Engine>
  </Service>
</Server>

Spring - Drag & Drop 파일 업로드 (img_type, img_id 속성 추가)

한 페이지내에서 여러개의 파일 업로드를 구현하기 위해서 img_type, img_id 속성을 추가해서 여러개의 업로드가 발생하더라고 구분 할 수 있게 구현

html 페이지

<div class="dragAndDropDiv" img_type="uploadarea" img_id="1">
<div class="dragAndDropDiv" img_type="uploadarea" img_id="2">

파일 올려진 경우 이벤트에서 img_type, img_id 속성 가져오기 - javascript

	$(document).on("drop",".dragAndDropDiv",function(e){
		$(this).css('border', '2px dotted #0B85A1');
		e.preventDefault();
		var files = e.originalEvent.dataTransfer.files;

		// img_type, img_id 속성 가져오기
		var img_type = $(e.target).attr('img_type');
		var img_id = $(e.target).attr('img_id');

		handleFileUpload(img_type, img_id, files,objDragAndDrop);
	});

FormData 구성 img_type, img_id 포함 - javascript

	function handleFileUpload(img_type, img_id, files,obj) {
		for (var i = 0; i < files.length; i++) {
			var fd = new FormData();
			fd.append('img_type', img_type);
			fd.append('img_id', img_id);
			fd.append('file', files[i]);

			var status = undefined;
			//var status = new createStatusbar(obj); //Using this we can set progress.
			//status.setFileNameSize(files[i].name,files[i].size);
			sendFileToServer(fd,status);
		}
	}

업로드 완료 처리 - javascript

img_type이 request인 경우 img테그의 src 속성 값 변경 처리

function sendFileToServer(formData,status) {
	var uploadURL = "<c:url value="/dragdrop/fileUpload/post.do"/>"; //Upload URL

... 생략 ...

		data: formData,
		success: function(data) { // 업로드가 완료되면 호출되는 메소드
			if (status != undefined) {
				status.setProgress(100);
			}

			//
			console.log('img_type = ' + data.img_type);
			console.log('img_id = ' + data.img_id);
			$.each(data.files, function(index, file) {
				console.log('filename = ' + file);

				if (data.img_type=='request') {
					var targetObj = $(".dragAndDropDiv[img_type='"+data.img_type+"'][img_id='"+data.img_id+"']");
					targetObj.attr('src', '/test/' + file);
					targetObj.attr('uuid', file);
				}
			});
		}
	});

javascript 전체

$(document).ready(function() {

	var objDragAndDrop = $(".dragAndDropDiv");

	$(document).on("dragenter",".dragAndDropDiv",function(e){
		e.stopPropagation();
		e.preventDefault();
		$(this).css('border', '2px solid #0B85A1');
	});
	$(document).on("dragover",".dragAndDropDiv",function(e){
		e.stopPropagation();
		e.preventDefault();
	});
	$(document).on("drop",".dragAndDropDiv",function(e){
		$(this).css('border', '2px dotted #0B85A1');
		e.preventDefault();
		var files = e.originalEvent.dataTransfer.files;

		// img_type, img_id 속성 가져오기
		var img_type = $(e.target).attr('img_type');
		var img_id = $(e.target).attr('img_id');

		handleFileUpload(img_type, img_id, files,objDragAndDrop);
	});
	$(document).on('dragenter', function (e){
		e.stopPropagation();
		e.preventDefault();
	});
	$(document).on('dragover', function (e){
		e.stopPropagation();
		e.preventDefault();
		objDragAndDrop.css('border', '2px dotted #0B85A1');
	});
	$(document).on('drop', function (e){
		e.stopPropagation();
		e.preventDefault();
	});

	function handleFileUpload(img_type, img_id, files,obj) {
		for (var i = 0; i < files.length; i++) {
			var fd = new FormData();
			fd.append('img_type', img_type);
			fd.append('img_id', img_id);
			fd.append('file', files[i]);

			var status = undefined;
			//var status = new createStatusbar(obj); //Using this we can set progress.
			//status.setFileNameSize(files[i].name,files[i].size);
			sendFileToServer(fd,status);
		}
	}

	var rowCount=0;
	function createStatusbar(obj){

		rowCount++;
		var row="odd";
		if(rowCount %2 ==0) row ="even";
		this.statusbar = $("<div class='statusbar "+row+"'></div>");
		this.filename = $("<div class='filename'></div>").appendTo(this.statusbar);
		this.size = $("<div class='filesize'></div>").appendTo(this.statusbar);
		this.progressBar = $("<div class='progressBar'><div></div></div>").appendTo(this.statusbar);
		this.abort = $("<div class='abort'>중지</div>").appendTo(this.statusbar);

		obj.after(this.statusbar);

		this.setFileNameSize = function(name,size){
			var sizeStr="";
			var sizeKB = size/1024;
			if(parseInt(sizeKB) > 1024) {
				var sizeMB = sizeKB/1024;
				sizeStr = sizeMB.toFixed(2)+" MB";
			} else {
				sizeStr = sizeKB.toFixed(2)+" KB";
			}

			this.filename.html(name);
			this.size.html(sizeStr);
		}

		this.setProgress = function(progress){
			var progressBarWidth =progress*this.progressBar.width()/ 100;
			this.progressBar.find('div').animate({ width: progressBarWidth }, 10).html(progress + "% ");
			if(parseInt(progress) >= 100) {
				this.abort.hide();
			}
		}

		this.setAbort = function(jqxhr){
			var sb = this.statusbar;
			this.abort.click(function() {
				jqxhr.abort();
				sb.hide();
			});
		}
	}

	function sendFileToServer(formData,status) {
		var uploadURL = "<c:url value="/dragdrop/fileUpload/post.do"/>"; //Upload URL
		var extraData ={}; //Extra Data.
		var jqXHR=$.ajax({
				xhr: function() {
				var xhrobj = $.ajaxSettings.xhr();
				if (xhrobj.upload) {
					xhrobj.upload.addEventListener('progress', function(event) {
						var percent = 0;
						var position = event.loaded || event.position;
						var total = event.total;
						if (event.lengthComputable) {
							percent = Math.ceil(position / total * 100);
						}
						//Set progress
						if (status != undefined) {
							status.setProgress(percent);
						}
					}, false);
				}
				return xhrobj;
			},
			url: uploadURL,
			type: "POST",
			dataType : 'json',
			contentType:false,
			processData: false,
			cache: false,
			data: formData,
			success: function(data) { // 업로드가 완료되면 호출되는 메소드
				if (status != undefined) {
					status.setProgress(100);
				}

				//
				console.log('img_type = ' + data.img_type);
				console.log('img_id = ' + data.img_id);
				$.each(data.files, function(index, file) {
					console.log('filename = ' + file);

					if (data.img_type=='request') {
						var targetObj = $(".dragAndDropDiv[img_type='"+data.img_type+"'][img_id='"+data.img_id+"']");
						targetObj.attr('src', '/test/' + file);
						targetObj.attr('uuid', file);
					} else {
						var uploadTbody = $('#uploadTbody');
						var row = $('<span style="display : block;"></span>');
						row.text(file);
						uploadTbody.append(row);

						// 배열 초기화
						var uploadFilenames = new Array(9);
						for (i=0; i<uploadFilenames.length; i++) {
							uploadFilenames[i] = '';
						}
						var t_fileList = $('#uploadTbody>span');

						/*
						for (i=1; i<=t_fileList.length; i++) {
							var file_value = $('#uploadTbody>span:nth-child('+i+')');
							console.log(i + '/' + file_value.text());
							uploadFilenames[i-1] = file_value.text();
						}
						*/

						console.log(t_fileList.length);
						$.each( t_fileList, function( key, value ) {
							console.log( key + ": " + $(value).text() );
							uploadFilenames[key] = $(value).text();
						});

						console.log(uploadFilenames[0]);
						console.log(uploadFilenames[1]);
						console.log(uploadFilenames[2]);
						console.log(uploadFilenames[3]);
					}
				});

				//$("#status1").append("File upload Done<br>");
			}
		});

		if (status != undefined) {
			status.setAbort(jqXHR);
		}
	}
});

업로드 메소드

	@RequestMapping(value = "/dragdrop/fileUpload/post.do") // ajax에서 호출하는 부분
	@ResponseBody
	public String upload(
			@RequestParam(value = "img_type", required = false, defaultValue = "") String img_type,
			@RequestParam(value = "img_id", required = false, defaultValue = "-1") int img_id,
			MultipartHttpServletRequest multipartRequest) // Multipart로 받는다.
	{

		System.out.println("img_type = " + img_type + "/img_id = " + img_id);

		Iterator<String> itr = multipartRequest.getFileNames();

		String filePath = "C:/test"; // 설정파일로 뺀다.
		String targetFilename = "";

		JSONArray filenames = new JSONArray();

		while (itr.hasNext()) { // 받은 파일들을 모두 돌린다.

			/*
			 * 기존 주석처리 MultipartFile mpf = multipartRequest.getFile(itr.next());
			 * String originFileName = mpf.getOrigin'alFilename(); System.out.println(
			 * "FILE_INFO: "+originFileName); //받은 파일 리스트 출력
			 */

			MultipartFile mpf = multipartRequest.getFile(itr.next());

			String originalFilename = mpf.getOriginalFilename(); // 파일명

			// 파일 확장자 추출
			String fileExt = FileUtils.getFileExt(originalFilename);

			UUID uuid = UUID.randomUUID();
			targetFilename = uuid.toString() + "." + fileExt.toLowerCase();

			String fileFullPath = filePath + "/" + targetFilename; // 파일 전체 경로

			try {
				// 파일 저장
				mpf.transferTo(new File(fileFullPath)); // 파일저장 실제로는 service에서 처리

				System.out.println("originalFilename => " + originalFilename);
				System.out.println("fileFullPath => " + fileFullPath);

			} catch (Exception e) {
				System.out.println("postTempFile_ERROR======>" + fileFullPath);
				e.printStackTrace();
			}

			filenames.add(targetFilename);

		}

		JSONObject jobj = new JSONObject();
		jobj.put("img_type", img_type);
		jobj.put("img_id", img_id);
		jobj.put("files", filenames);

		return jobj.toJSONString();
	}
저작자 표시
신고

BPI-M2+ mjpg-streamer

OS/Raspberry Pi 2017.02.26 04:49 Posted by 파란크리스마스

BPI-M2+ mjpg-streamer

출처 : 【BPI-M2+】之mjpg-streamer测试和体验- Bananap讨论区- 烽火社区 ...
MJPG-Streamer › Wiki › ubuntuusers.de
라즈베리파이에서 웹캠 mjpg-streamer 따라하기|작성자 서리
mjpg-streamer 웹캠 영상 스트리밍 | Mungrrr

관련 라이브러리 설치

$ sudo apt-get install libjpeg8-dev libv4l-dev subversion
$ sudo apt-get install imagemagick

mjpg-streamer 컴파일 및 설치

출처 : http://www.lavrsen.dk/svn/motion/tags/3.2.9/picture.c

$ svn co https://svn.code.sf.net/p/mjpg-streamer/code/mjpg-streamer mjpg-streamer
$ cd mjpg-streamer
$ make USE_LIBV4L2=true clean all
$ sudo make install
install --mode=755 mjpg_streamer /usr/local/bin
install --mode=644 input_ov5640.so input_uvc.so output_file.so output_udp.so output_http.so input_testpicture.so input_file.so /usr/local/lib/
install --mode=755 -d /usr/local/www
install --mode=644 -D www/* /usr/local/www

input_ov5640.so

input_ov5640.tar.gz

mjpg-streamer의 input_uvc.so는 YUV만 지원하고, BPI-M2+의 카메라인 OV5640는 YUV420코덱만 지원하기 때문에, mjpg-streamer에서 사용 할 수 없습니다.

제가 작업한 OV5640의 YUV420코덱을 지원하는 so 파일을 공개 합니다.
BPI-M2+의 카메라인 OV5640를 사용해서 mjpg-streamer로 스크리밍 하시려면 첨부한 파일을 사용하세요.

LD_LIBRARY_PATH 경로 추가

$ echo "export LD_LIBRARY_PATH=\$LD_LIBRARY_PATH:/usr/local/lib:/usr/local/lib/mjpg-streamer" | sudo tee -a /etc/profile

mjpg-streamer 실행

$ ./mjpg_streamer -i "./input_ov5640.so -y -n" -o "./output_http.so -w ./www"
MJPG Streamer Version: svn rev: 3:172M
 i: Using V4L2 device.: /dev/video0
 i: Desired Resolution: 640 x 480
 i: Frames Per Second.: 5
 i: Format............: YUV420
 i: JPEG Quality......: 80
 o: www-folder-path...: ./www/
 o: HTTP TCP port.....: 8080
 o: username:password.: disabled
 o: commands..........: enabled

서비스등록

$ sudo vi /etc/init.d/mjpg_streamer

mjpg_streamer 파일 내용

#!/bin/bash
# /etc/init.d/mjpg_streamer.sh
# v0.2 phillips321.co.uk
### BEGIN INIT INFO
# Provides:          mjpg_streamer.sh
# Required-Start:    $network
# Required-Stop:     $network
# Default-Start:     2 3 4 5
# Default-Stop:      0 1 6
# Short-Description: mjpg_streamer for webcam
# Description:       Streams /dev/video0 to http://IP/?action=stream
### END INIT INFO

#
export width=640
export height=480
export fps=10
export SHUTDOWN_WAIT=2
export QUALITY=75

if [ -n "$2" ]; then
  width=$2
fi

if [ -n "$3" ]; then
  height=$3
fi

if [ -n "$4" ]; then
  fps=$4
fi

export LD_MJPG_STREAMER=/usr/local/lib

f_message(){
        echo "[+] $1"
}

mjpg_streamer_pid() {
  echo `ps aux | grep mjpg_streamer | grep -v grep | awk '{ print $2 }'`
}

start() {
  pid=$(mjpg_streamer_pid)
  if [ -n "$pid" ]
  then
    echo "mjpg_streamer is already running (pid: $pid)"
  else
    # Start mjpg_streamer
		f_message "Starting mjpg_streamer"
		mjpg_streamer -b -i "$LD_MJPG_STREAMER/input_ov5640.so -r "$width"x"$height" -f $fps -q $QUALITY -y" -o "$LD_MJPG_STREAMER/output_http.so -p 8080 -w /usr/local/www"
		sleep 2
		f_message "mjpg_streamer started"
  fi

  return 0
}

stop() {
  pid=$(mjpg_streamer_pid)
  if [ -n "$pid" ]
  then
    f_message "Stopping mjpg_streamer..."
    kill -9 $pid

    let kwait=$SHUTDOWN_WAIT
    let count=0;
    until [ `ps -p $pid | grep -c $pid` = '0' ] || [ $count -gt $kwait ]
    do
      echo -n -e "\nwaiting for processes to exit";
      sleep 1
      let count=$count+1;
    done

    if [ $count -gt $kwait ]; then
      echo -n -e "\nkilling processes which didn't stop after $SHUTDOWN_WAIT seconds\n"
      kill -9 $pid
    fi
  else
    echo "mjpg_streamer is not running"
  fi

  return 0
}

# Carry out specific functions when asked to by the system
case "$1" in
        start)
                 start
                 ;;
        stop)
                 stop
                 ;;
        restart)
                 stop
                 sleep 2
                 start
                 ;;
        resolution)
                resolution=`ps axu | grep mjpg_streamer | grep -v grep | awk '{ print $16 }'`
                currfps=`ps axu | grep mjpg_streamer | grep -v grep | awk '{ print $18 }'`
                if [ -n "$resolution" ];
                then
                        echo "${resolution}"x"$currfps"
                else
                        echo "0x0x0"
                fi
                ;;
        status)
                pid=`ps -A | grep mjpg_streamer | grep -v "grep" | grep -v mjpg_streamer. | awk '{print $1}' | head -n 1`
                if [ -n "$pid" ];
                then
                        f_message "mjpg_streamer is running with pid ${pid}"
                        f_message "mjpg_streamer was started with the following command line"
                        cat /proc/${pid}/cmdline ; echo ""
                else
                        f_message "Could not find mjpg_streamer running"
                fi
                ;;
        *)
                f_message "Usage: $0 {start|stop|status|restart}"
                exit 1
                ;;
esac
exit 0

등록

$ sudo chmod u+x /etc/init.d/mjpg_streamer
$ sudo update-rc.d mjpg_streamer defaults

서비스 실행 및 실행 확인

$ sudo service mjpg_streamer start
$ sudo service mjpg_streamer status

● mjpg_streamer.service - LSB: mjpg_streamer for webcam
   Loaded: loaded (/etc/init.d/mjpg_streamer; bad; vendor preset: enabled)
   Active: active (running) since Sat 2017-03-11 23:04:13 CST; 15min ago
     Docs: man:systemd-sysv-generator(8)
  Process: 4201 ExecStart=/etc/init.d/mjpg_streamer start (code=exited, status=0/SUCCESS)
   CGroup: /system.slice/mjpg_streamer.service
           └─4015 mjpg_streamer -b -i /usr/local/lib/input_ov5640.so -r 1280x720 -f 24 -q 45 -y -o /usr/local/lib/output_http.so -p 8080 -w /usr/local/www

Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4201]: [+] Starting mjpg_streamer
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4201]: enabling daemon modeforked to background (4210)
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: MJPG Streamer Version: svn rev: 3:172M
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: Using V4L2 device.: /dev/video0
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: Desired Resolution: 640 x 480
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: Frames Per Second.: 10
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: Format............: YUV420
Mar 11 23:04:11 bpi-iot-ros-ai mjpg_streamer[4210]: MJPG-streamer [4210]: JPEG Quality......: 75
Mar 11 23:04:13 bpi-iot-ros-ai mjpg_streamer[4201]: [+] mjpg_streamer started
Mar 11 23:04:13 bpi-iot-ros-ai systemd[1]: Started LSB: mjpg_streamer for webcam.

실행

motion

출처 : mjpegtoyuv420p patch for Logitech Quickcam Pro

$ svn co http://www.lavrsen.dk/svn/motion/trunk motion
$ cd motion
$ ./configure
$ make
저작자 표시
신고

BPI-M2+ Camera(OV5640)

OS/Raspberry Pi 2017.02.26 04:27 Posted by 파란크리스마스

BPI-M2+ Camera(OV5640)

출처 : BPI-M2+ OV5640 camera linux driver is work fine
BPI-M2+ camera module

Camera 모듈 설치

$ sudo vi /etc/modules

내용 추가

ov5640
vfe_v4l2

Camera 설치 확인

$ dmesg | grep ov5640
[    8.330079] [VFE]Find sensor name is "ov5640", i2c address is 78, type is "YUV" !
[    8.330090] [VFE]Sub device register "ov5640" i2c_addr = 0x78 start!
[    8.535088] [VFE]Sub device register "ov5640" is OK!
$ ls /dev/video*
/dev/video0

Camera 정보

$ modinfo ov5640
filename:       /lib/modules/3.4.112-sun8i/kernel/drivers/media/video/sunxi-vfe/device/ov5640.ko
license:        GPL
description:    A low-level driver for ov5640 sensors
author:         raymonxiu
alias:          i2c:ov5640
depends:        cci,vfe_subdev
intree:         Y
vermagic:       3.4.112-sun8i SMP preempt mod_unload modversions ARMv7 p2v8

Camera 캡쳐 프로그램 컴파일 및 실행

출처 : https://github.com/avafinger/ov5640

$ git clone https://github.com/avafinger/cap-v4l2
$ cd cap-v4l2
$ sudo ./install_deps.sh
$ ./build_script.sh
$ ./cap 1280 720 4 1 -999 -1 -1
저작자 표시
신고




티스토리 툴바
