Raspberry Pi - HC-SR04 (초음파센서)로 거리측정하기

OS/Raspberry Pi 2017.08.19 12:26 Posted by 파란크리스마스

출처 : Using a Raspberry Pi distance sensor (ultrasonic sensor HC-SR04)

배선

Python 소스

<#Libraries
import RPi.GPIO as GPIO
import time

#GPIO Mode (BOARD / BCM)
GPIO.setmode(GPIO.BCM)

#set GPIO Pins
GPIO_TRIGGER = 23
GPIO_ECHO = 24

#set GPIO direction (IN / OUT)
GPIO.setup(GPIO_TRIGGER, GPIO.OUT)
GPIO.setup(GPIO_ECHO, GPIO.IN)

def distance():
    # set Trigger to HIGH
    GPIO.output(GPIO_TRIGGER, True)

    # set Trigger after 0.01ms to LOW
    time.sleep(0.00001)
    GPIO.output(GPIO_TRIGGER, False)

    StartTime = time.time()
    StopTime = time.time()

    # save StartTime
    while GPIO.input(GPIO_ECHO) == 0:
        StartTime = time.time()

    # save time of arrival
    while GPIO.input(GPIO_ECHO) == 1:
        StopTime = time.time()

    # time difference between start and arrival
    TimeElapsed = StopTime - StartTime
    # multiply with the sonic speed (34300 cm/s)
    # and divide by 2, because there and back
    distance = (TimeElapsed * 34300) / 2

    return distance

if __name__ == '__main__':
    try:
        while True:
            dist = distance()
            print ("Measured Distance = %.1f cm" % dist)
            time.sleep(1)

        # Reset by pressing CTRL + C
    except KeyboardInterrupt:
        print("Measurement stopped by User")
        GPIO.cleanup()

실행

$ python3 ultrasonic_distance.py
Measured Distance = 191.9 cm
Measured Distance = 9.2 cm
Measured Distance = 10.5 cm
Measured Distance = 205.9 cm
Measured Distance = 25.4 cm
Measured Distance = 29.9 cm
Measured Distance = 17.1 cm
Measured Distance = 22.2 cm
Measured Distance = 10.2 cm
^CMeasurement stopped by User
저작자 표시
신고

Python - mjpeg 영상 화면에 출력

OS/Raspberry Pi 2017.08.16 00:15 Posted by 파란크리스마스

출처 : python - How to parse mjpeg http stream from ip camera? - Stack Overflow

Python - mjpeg 영상 화면에 출력

import cv2
import requests
import numpy as np

#stream = urllib.request.urlopen("http://127.0.0.1:8080/?action=snapshot")
#stream = urllib2.urlopen("http://127.0.0.1:8080/?action=snapshot")
#bytes = bytes()

while True:
    r = requests.get('http://127.0.0.1:8080/?action=snapshot"', auth=('user', 'password'), stream=True)
    if(r.status_code == 200):
        bytes = b''
        for chunk in r.iter_content(chunk_size=1024):
            bytes += chunk
            a = bytes.find(b'\xff\xd8')
            b = bytes.find(b'\xff\xd9')
            if a != -1 and b != -1:
                jpg = bytes[a:b+2]
                bytes = bytes[b+2:]
                i = cv2.imdecode(np.fromstring(jpg, dtype=np.uint8), cv2.IMREAD_COLOR)
                cv2.imshow('i', i)
                if cv2.waitKey(1) == 27:
                    exit(0)
    else:
        print("Received unexpected status code {}".format(r.status_code))


저작자 표시
신고

Arduino Uno - L298N & HC-06

OS/Arduino 2017.08.07 00:59 Posted by 파란크리스마스

출처 : [아두이노] 블루투스 모듈(HC-06) 사용하기 (설정, 문자열 전송, LED ON/OFF)

Arduino Uno - L298N & HC-06

#include <SoftwareSerial.h> //시리얼 통신 라이브러리 호출

int blueTx=3;   //Tx (보내는핀 설정)
int blueRx=2;   //Rx (받는핀 설정)

SoftwareSerial btSerial(blueTx, blueRx);  //시리얼 통신을 위한 객체선언
String myString=""; //받는 문자열

//모터드라이버핀과 아두이노의 연결번호
#define EA A0
#define EB A1
#define M_IN1 7
#define M_IN2 6
#define M_IN3 5
#define M_IN4 4

int motorA_vector = 1;//모터의 회전방향이 반대일시 0을 1로 1을 0으로 바꿔주시면 모터의 회전방향이 바뀝니다.
int motorB_vector = 1;//모터의 회전방향이 반대일시 0을 1로 1을 0으로 바꿔주시면 모터의 회전방향이 바뀝니다.

int motor_speed = 255;//모터 스피드

const int DELAY = 1000;

void setup() {
  Serial.begin(9600);   //시리얼모니터
  btSerial.begin(9600); //블루투스 시리얼 개방

  //모터관련 핀들을 출력으로 설정한다.
  pinMode(EA, OUTPUT);
  pinMode(EB, OUTPUT);
  pinMode(M_IN1, OUTPUT);
  pinMode(M_IN2, OUTPUT);
  pinMode(M_IN3, OUTPUT);
  pinMode(M_IN4, OUTPUT);

  //
  delay(3000);//3초 지연
  motorstop();
}

void loop()
{
  // selfTest();
  while(btSerial.available())  //mySerial에 전송된 값이 있으면
  {
    char myChar = (char)btSerial.read();  //mySerial int 값을 char 형식으로 변환
    myString+=myChar;   //수신되는 문자를 myString에 모두 붙임 (1바이트씩 전송되는 것을 연결)
    delay(5);           //수신 문자열 끊김 방지
  }
  if(!myString.equals(""))  //myString 값이 있다면
  {
    Serial.println("input value: "+myString); //시리얼모니터에 myString값 출력

    if (myString.equals("S")) {
      motorstop();
    } else if (myString.equals("F")) {
      forward();
    } else if (myString.equals("B")) {
      backward();
    } else if (myString.equals("L")) {
      left();
    } else if (myString.equals("R")) {
      right();
    }
    myString="";  //myString 변수값 초기화
  }
}

void selfTest()
{
   motor_con(motor_speed, motor_speed); //전진
   //motor_con(-motor_speed, motor_speed); //좌회전
   //motor_con(motor_speed, -motor_speed); //우회전
   //motor_con(-motor_speed, -motor_speed); //후전
   delay(DELAY);
   motor_con(0, 0); //정지
   delay(DELAY);
}

void selfTest2()
{
  forward();
  delay(DELAY);
  motorstop(); delay(500);

  backward();
  delay(DELAY);
  motorstop(); delay(500);

  right();
  delay(DELAY);
  motorstop(); delay(500);

  left();
  delay(DELAY);
  motorstop(); delay(500);
}

void motorstop()
{
  motor_con(0, 0); //정지
}

void backward()
{
  motor_con(-motor_speed, -motor_speed); //후전
}

void forward()
{
  motor_con(motor_speed, motor_speed); //전진
}

// Let right motor keep running, but stop left motor
void right()
{
  motor_con(motor_speed, -motor_speed); //우회전
}

// Let left motor keep running, but stop right motor
void left()
{
  motor_con(-motor_speed, motor_speed); //좌회전
}

void motor_con(int M1, int M2){

 if(M1>0){  //모터A 정회전
   digitalWrite(M_IN1,motorA_vector);
   digitalWrite(M_IN2,!motorA_vector);
 }
 else if(M1<0){  //모터A 역회전
   digitalWrite(M_IN1,!motorA_vector);
   digitalWrite(M_IN2,motorA_vector);
 }
 else{        //모터 A 정지
   digitalWrite(M_IN1,LOW);
   digitalWrite(M_IN2,LOW);
 }

 if(M2>0){    //모터B 정회전
   digitalWrite(M_IN3,motorB_vector);
   digitalWrite(M_IN4,!motorB_vector);
 }
 else if(M2<0){  //모터B 역회전
   digitalWrite(M_IN3,!motorB_vector);
   digitalWrite(M_IN4,motorB_vector);
 }
 else{          //모터 B 정지
   digitalWrite(M_IN3,LOW);
   digitalWrite(M_IN4,LOW);
 }
 analogWrite(EA,abs(M1)); //A모터 속도값
 analogWrite(EB,abs(M2)); //B모터 속도값
}
저작자 표시
신고

Arduino Pro Mini

OS/Arduino 2017.08.06 01:42 Posted by 파란크리스마스

출처 : 라즈베리파이 USB to TTL Serial Cable 연결 :: tibyte.kr - 티바이트

Arduino Pro Mini - 시리얼 케이블 연결

흰색 선(RXD)을 라즈베리파이의 TXD핀에 연결하고,
초록 선(TXD)을 라즈베리파이의 RXD핀에 연결한다.

업로드

Arduino Pro Mini의 경우 리셋을 수동으로 해야 되므로, 컴파일전에 [리셋]버튼을 누리고 있다가, [업로드...]라고 나올때 [리셋]버튼을 때준다.

L298N 모터드라이버 제어

//모터드라이버핀과 아두이노의 연결번호
#define EA 2
#define EB 7
#define M_IN1 3
#define M_IN2 4
#define M_IN3 5
#define M_IN4 6

int motorA_vector = 1;//모터의 회전방향이 반대일시 0을 1로 1을 0으로 바꿔주시면 모터의 회전방향이 바뀝니다.
int motorB_vector = 1;//모터의 회전방향이 반대일시 0을 1로 1을 0으로 바꿔주시면 모터의 회전방향이 바뀝니다.

int motor_speed = 150; // 255;//모터 스피드

const int DELAY = 1000;

void setup() {
  Serial.begin(9600);   //시리얼모니터

  //모터관련 핀들을 출력으로 설정한다.
  pinMode(EA, OUTPUT);
  pinMode(EB, OUTPUT);
  pinMode(M_IN1, OUTPUT);
  pinMode(M_IN2, OUTPUT);
  pinMode(M_IN3, OUTPUT);
  pinMode(M_IN4, OUTPUT);

  //
  delay(3000);//3초 지연
  motorstop();
}

void loop() {
  selfTest();
}

void selfTest()
{
   motor_con(motor_speed, motor_speed); //전진
   //motor_con(-motor_speed, motor_speed); //좌회전
   //motor_con(motor_speed, -motor_speed); //우회전
   //motor_con(-motor_speed, -motor_speed); //후전
   delay(DELAY);
   motor_con(0, 0); //정지
   delay(DELAY);
}

void motorstop()
{
  motor_con(0, 0); //정지
}

void motor_con(int M1, int M2){

 if(M1>0){  //모터A 정회전
   digitalWrite(M_IN1,motorA_vector);
   digitalWrite(M_IN2,!motorA_vector);
 }
 else if(M1<0){  //모터A 역회전
   digitalWrite(M_IN1,!motorA_vector);
   digitalWrite(M_IN2,motorA_vector);
 }
 else{        //모터 A 정지
   digitalWrite(M_IN1,LOW);
   digitalWrite(M_IN2,LOW);
 }

 if(M2>0){    //모터B 정회전
   digitalWrite(M_IN3,motorB_vector);
   digitalWrite(M_IN4,!motorB_vector);
 }
 else if(M2<0){  //모터B 역회전
   digitalWrite(M_IN3,!motorB_vector);
   digitalWrite(M_IN4,motorB_vector);
 }
 else{          //모터 B 정지
   digitalWrite(M_IN3,LOW);
   digitalWrite(M_IN4,LOW);
 }
 analogWrite(EA,abs(M1)); //A모터 속도값
 analogWrite(EB,abs(M2)); //B모터 속도값
}
저작자 표시
신고

Raspberry PI -무선랜카드 AP모드로 사용하기

OS/Raspberry Pi 2017.05.22 23:31 Posted by 파란크리스마스

Raspberry PI -무선랜카드 AP모드로 사용하기

출처 : Using your new Raspberry Pi 3 as a WiFi access point with hostapd
라즈베리파이 활용강좌 : 라즈베리파이를 무선공유기(AP)로 활용하기 |
SETTING UP A RASPBERRY PI AS AN ACCESS POINT IN A STANDALONE NETWORK

최신으로 업데이트

$ sudo apt-get update;sudo apt-get upgrade -y

AP 관련 패키지 설치

$ sudo apt-get install hostapd bridge-utils iw
$ sudo apt-get install dnsmasq

wlan0 고정 아이피 설정

$ sudo vi /etc/dhcpcd.conf

아래 내용 하단에 추가

denyinterfaces wlan0

Network 설정 파일 백업하고 수정

$ sudo cp /etc/network/interfaces /etc/network/interfaces.bak
$ sudo vi /etc/network/interfaces

# interfaces(5) file used by ifup(8) and ifdown(8)

# Please note that this file is written to be used with dhcpcd
# For static IP, consult /etc/dhcpcd.conf and 'man dhcpcd.conf'

# Include files from /etc/network/interfaces.d:
source-directory /etc/network/interfaces.d

auto lo
iface lo inet loopback

iface eth0 inet manual

allow-hotplug wlan0
iface wlan0 inet static
    address 192.168.0.1
    netmask 255.255.255.0
    network 192.168.1.0
    broadcast 192.168.0.255
#    wpa-conf /etc/wpa_supplicant/wpa_supplicant.conf

allow-hotplug wlan1
iface wlan1 inet manual
    wpa-conf /etc/wpa_supplicant/wpa_supplicant.conf

wlan 다시 시작

$ sudo service dhcpcd restart
$ sudo ifdown wlan0
$ sudo ifup wlan0

DHCP 서버 설정

$ sudo mv /etc/dnsmasq.conf /etc/dnsmasq.conf.orig
$ sudo vi /etc/dnsmasq.conf

interface=wlan0      # Use interface wlan0
listen-address=192.168.0.1 # Explicitly specify the address to listen on
bind-interfaces      # Bind to the interface to make sure we aren't sending things elsewhere
server=8.8.8.8       # Forward DNS requests to Google DNS
domain-needed        # Don't forward short names
bogus-priv           # Never forward addresses in the non-routed address spaces.
dhcp-range=192.168.0.2,192.168.0.20,255.255.255.0,24h # Assign IP addresses between 192.168.0.2 and 192.168.0.20 with a 24 hour lease time

hostapd.conf 파일 생성

$ sudo vi /etc/hostapd/hostapd.conf

# This is the name of the WiFi interface we configured above
interface=wlan0

# Use the nl80211 driver with the brcmfmac driver
driver=nl80211

# This is the name of the network
ssid=Pi3-AP

# Use the 2.4GHz band
hw_mode=g

# Use channel 6
channel=6

# Enable 802.11n
ieee80211n=1

# Enable WMM
wmm_enabled=1

# Enable 40MHz channels with 20ns guard interval
ht_capab=[HT40][SHORT-GI-20][DSSS_CCK-40]

# Accept all MAC addresses
macaddr_acl=0

# Use WPA authentication
auth_algs=1

# Require clients to know the network name
ignore_broadcast_ssid=0

# Use WPA2
wpa=2

# Use a pre-shared key
wpa_key_mgmt=WPA-PSK

# The network passphrase
wpa_passphrase=raspberry

# Use AES, instead of TKIP
rsn_pairwise=CCMP

default hostapd 파일 수정

$ sudo vi /etc/default/hostapd

DAEMON_CONF="/etc/hostapd/hostapd.conf"

서비스 다시 시작

$ sudo service hostapd start
$ sudo service dnsmasq start
저작자 표시
신고

Ubuntu 디스크 mount 하기

OS/Linux 2017.04.19 14:03 Posted by 파란크리스마스

Ubuntu 디스크 mount 하기

출처 : Mint & Latte_. :: 리눅스에서 하드디스크 mount 하기

추가된 디스트 Volume 확인

$ sudo fdisk -l

Disk /dev/vda: 42.9 GB, 42949672960 bytes
16 heads, 63 sectors/track, 83220 cylinders, total 83886080 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk identifier: 0x000648d6

   Device Boot      Start         End      Blocks   Id  System
/dev/vda1            2048     3905535     1951744   82  Linux swap / Solaris
/dev/vda2   *     3905536    83885759    39990112   83  Linux

Disk /dev/vdb: 214.7 GB, 214748364800 bytes
16 heads, 63 sectors/track, 416101 cylinders, total 419430400 sectors
Units = sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disk identifier: 0x00000000

Disk /dev/vdb doesn't contain a valid partition table

파일시스템 생성

$ sudo mkfs.ext4 /dev/vdb
mke2fs 1.42.9 (4-Feb-2014)
Filesystem label=
OS type: Linux
Block size=4096 (log=2)
Fragment size=4096 (log=2)
Stride=0 blocks, Stripe width=0 blocks
13107200 inodes, 52428800 blocks
2621440 blocks (5.00%) reserved for the super user
First data block=0
Maximum filesystem blocks=4294967296
1600 block groups
32768 blocks per group, 32768 fragments per group
8192 inodes per group
Superblock backups stored on blocks:
        32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
        4096000, 7962624, 11239424, 20480000, 23887872

Allocating group tables: done
Writing inode tables: done
Creating journal (32768 blocks): done
Writing superblocks and filesystem accounting information: done

mount 받을 디렉토리 생성

$ sudo mkdir /bluexmas_db

mount 하기

$ sudo mount /dev/vdb /bluexmas_db

mount 확인

$ df -h
Filesystem      Size  Used Avail Use% Mounted on
udev            2.0G   12K  2.0G   1% /dev
tmpfs           396M  364K  395M   1% /run
/dev/vda2        38G  1.6G   35G   5% /
none            4.0K     0  4.0K   0% /sys/fs/cgroup
none            5.0M     0  5.0M   0% /run/lock
none            2.0G     0  2.0G   0% /run/shm
none            100M     0  100M   0% /run/user
/dev/vdb        197G   60M  187G   1% /bluexmas_db

unmount 하기

$ sudo umount /bluexmas_db

unmount 확인

$ df -h
Filesystem      Size  Used Avail Use% Mounted on
udev            2.0G   12K  2.0G   1% /dev
tmpfs           396M  372K  395M   1% /run
/dev/vda2        38G  9.2G   27G  26% /
none            4.0K     0  4.0K   0% /sys/fs/cgroup
none            5.0M     0  5.0M   0% /run/lock
none            2.0G     0  2.0G   0% /run/shm
none            100M     0  100M   0% /run/user

자동 mount

출처 : Ubuntu 14.04에 새로운 하드디스크 추가 및 포맷후 자동 마운트 설정

UUID 확인

$ sudo blkid
/dev/vda1: UUID="4874a47d-f878-440c-95d0-297e6733abea" TYPE="swap"
/dev/vda2: UUID="20c996fb-8c20-4e7f-958e-84b7581af70f" TYPE="ext4"
/dev/vdb: UUID="6e0b7ac6-d17d-4829-839f-80662339cf6b" TYPE="ext4"
저작자 표시
신고

NanoPi M1 Plus - DHT11 control with pi4j

OS/NanoPi 2017.04.02 09:57 Posted by 파란크리스마스

NanoPi M1 Plus - DHT11 control with pi4j

출처 : Java Native Interface (JNI) - Java Programming Tutorial
Use arrays (JNI) - Real's Java How-to - Rgagnon
android - How to return an array from JNI to Java? - Stack Overflow

NanoPi M1 Plus에서 pi4j로만으로 DHT11센서의 값을 읽을 수 없어 pi4j의 native 코드를 추가해서 온도 값을 가지고 오도록 수정하였습니다. 첨부한 jar을 적용해서 사용하세요.

pi4j-core.jar

핀배열

 DHT11  BCM  GPIO  Name  Pin
 VCC      3.3v  1
 GND  0v  9
 Sensor  3  22  CTS2  15

dht11.h

int* read_dht11_dat(int pin);

dht11.c

/*
 *  dht11.c:
 *      Simple test program to test the wiringPi functions
 *      DHT11 test
 */

#include <wiringPi.h>

#include <stdio.h>
#include <stdlib.h>
#include <stdint.h>
#include <dht11.h>

#define MAXTIMINGS      85
#define DHTPIN    3
int dht11_dat[5] = { 0, 0, 0, 0, 0 };

int* read_dht11_dat(int pin) {
    uint8_t laststate       = HIGH;
    uint8_t counter  = 0;
    uint8_t j          = 0, i;
    float   f; /* fahrenheit */

    dht11_dat[0] = dht11_dat[1] = dht11_dat[2] = dht11_dat[3] = dht11_dat[4] = 0;

    /* pull pin down for 18 milliseconds */
    pinMode( pin, OUTPUT );
    digitalWrite( pin, LOW );
    delay( 18 );
    /* then pull it up for 40 microseconds */
    digitalWrite( pin, HIGH );
    delayMicroseconds( 40 );
    /* prepare to read the pin */
    pinMode( pin, INPUT );

    /* detect change and read data */
    for ( i = 0; i < MAXTIMINGS; i++ ) {
        counter = 0;
        while ( digitalRead( pin ) == laststate ) {
            counter++;
            delayMicroseconds( 1 );
            if ( counter == 255 ) {
                break;
            }
        }
        laststate = digitalRead( pin );

        if ( counter == 255 )
            break;

// printf("i = %d, j = %d\n", i, j);

        /* ignore first 3 transitions */
        if ( (i >= 4) && (i % 2 == 0) ) {
            /* shove each bit into the storage bytes */
            dht11_dat[j / 8] <<= 1;
            if ( counter > 16 )
                dht11_dat[j / 8] |= 1;
            j++;
        }
    }

    /*
     * check we read 40 bits (8bit x 5 ) + verify checksum in the last byte
     * print it out if data is good
     */
    if ( (j >= 40) && (dht11_dat[4] == ( (dht11_dat[0] + dht11_dat[1] + dht11_dat[2] + dht11_dat[3]) & 0xFF) ) ) {
        f = dht11_dat[2] * 9. / 5. + 32;
        //printf( "Humidity = %d.%d %% Temperature = %d.%d *C (%.1f *F)\n",
        //    dht11_dat[0], dht11_dat[1], dht11_dat[2], dht11_dat[3], f );
    } else {
        //printf( "Data not good, skip\n" );
    }

    return dht11_dat;
}

com_pi4j_wiringpi_Gpio.h 내용 추가

/*
 * Class:     com_pi4j_wiringpi_Gpio
 * Method:    readDHT11Data
 * Signature: (II)V
 */
JNIEXPORT jintArray JNICALL Java_com_pi4j_wiringpi_Gpio_readDHT11Data
  (JNIEnv *, jclass, jint);

com_pi4j_wiringpi_Gpio.c 내용 추가

#include <dht11.h>

/*
 * Class:     com_pi4j_wiringpi_Gpio
 * Method:    readDHT11Data
 * Signature: (II)V
 */
JNIEXPORT jintArray JNICALL Java_com_pi4j_wiringpi_Gpio_readDHT11Data
  (JNIEnv *env, jclass obj, jint pin)
{
    // return (jintArray) read_dht11_dat(pin);
    int size = 5;
    jintArray result;
    result = (*env)->NewIntArray(env, size);
    if (result == NULL) {
    	return NULL; /* out of memory error thrown */
    }

    int *a1 = read_dht11_dat(pin);

    int i;
    // fill a temp structure to use to populate the java int array
    jint fill[size];
    for (i = 0; i < size; i++) {
    	 fill[i] = a1[i]; // put whatever logic you want to populate the values here.
    }
    // move from the temp structure to the java structure
    (*env)->SetIntArrayRegion(env, result, 0, size, fill);
    return result;
}

Gpio 클래스 함수 추가

package com.pi4j.wiringpi;

public class Gpio {

    public static native int[] readDHT11Data(int pin);
}

DHT11_native.java

import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.NanoPiM1PlusGpioProvider;
import com.pi4j.wiringpi.Gpio;

public class DHT11_native {
    private static final int MAXTIMINGS = 85;
    private int[] dht11_dat = { 0, 0, 0, 0, 0 };

    private final static int DHTPIN = 3; // 3;

    public float getTemperature() {
    	float f = 0;
    	dht11_dat = Gpio.readDHT11Data(DHTPIN);

       if ( (dht11_dat[4] == ( (dht11_dat[0] + dht11_dat[1] + dht11_dat[2] + dht11_dat[3]) & 0xFF) ) ) {
      	 f = (float) (dht11_dat[2] * 9. / 5. + 32);
         System.out.println(String.format( "Humidity = %d.%d %% Temperature = %d.%d *C (%.1f *F)" , dht11_dat[0], dht11_dat[1], dht11_dat[2], dht11_dat[3], f) );
     } else {
    	 System.out.println( "Data not good, skip" );
     }

        return f;

    }

    private boolean checkParity() {
      return (dht11_dat[4] == ((dht11_dat[0] + dht11_dat[1] + dht11_dat[2] + dht11_dat[3]) & 0xFF));
    }

    public static void main (String ars[]) throws Exception {

    	GpioFactory.setDefaultProvider(new NanoPiM1PlusGpioProvider());

    	DHT11_native dht = new DHT11_native();

        for (int i=0; i<10; i++) {
           Thread.sleep(1000);
           dht.getTemperature();
        }

        System.out.println("Done!!");

    }
}

실행

# java -cp .:pi4j-core.jar DHT11_native
Data not good, skip
Humidity = 31.0 % Temperature = 23.0 *C (73.4 *F)
Humidity = 30.0 % Temperature = 23.0 *C (73.4 *F)
Humidity = 30.0 % Temperature = 23.0 *C (73.4 *F)

실행결과

저작자 표시
신고

NanoPi M1 Plus - DHT11 온도 습도 측정

OS/NanoPi 2017.03.28 00:20 Posted by 파란크리스마스

NanoPi M1 Plus - DHT11 온도 습도 측정

출처 : DHT11 Humidity & Temperature Sensor Module | UUGear

C 언어

/*
 *  dht11.c:
 *      Simple test program to test the wiringPi functions
 *      DHT11 test
 */

#include <wiringPi.h>

#include <stdio.h>
#include <stdlib.h>
#include <stdint.h>
#define MAXTIMINGS      85
#define DHTPIN	  7
int dht11_dat[5] = { 0, 0, 0, 0, 0 };

void read_dht11_dat() {
	uint8_t laststate       = HIGH;
	uint8_t counter	 = 0;
	uint8_t j	       = 0, i;
	float   f; /* fahrenheit */

	dht11_dat[0] = dht11_dat[1] = dht11_dat[2] = dht11_dat[3] = dht11_dat[4] = 0;

	/* pull pin down for 18 milliseconds */
	pinMode( DHTPIN, OUTPUT );
	digitalWrite( DHTPIN, LOW );
	delay( 18 );
	/* then pull it up for 40 microseconds */
	digitalWrite( DHTPIN, HIGH );
	delayMicroseconds( 40 );
	/* prepare to read the pin */
	pinMode( DHTPIN, INPUT );

	/* detect change and read data */
	for ( i = 0; i < MAXTIMINGS; i++ ) {
		counter = 0;
		while ( digitalRead( DHTPIN ) == laststate ) {
			counter++;
			delayMicroseconds( 1 );
			if ( counter == 255 ) {
				break;
			}
		}
		laststate = digitalRead( DHTPIN );

		if ( counter == 255 )
			break;

		/* ignore first 3 transitions */
		if ( (i >= 4) && (i % 2 == 0) ) {
			/* shove each bit into the storage bytes */
			dht11_dat[j / 8] <<= 1;
			if ( counter > 16 )
				dht11_dat[j / 8] |= 1;
			j++;
		}
	}

	/*
	 * check we read 40 bits (8bit x 5 ) + verify checksum in the last byte
	 * print it out if data is good
	 */
	if ( (j >= 40) && (dht11_dat[4] == ( (dht11_dat[0] + dht11_dat[1] + dht11_dat[2] + dht11_dat[3]) & 0xFF) ) ) {
		f = dht11_dat[2] * 9. / 5. + 32;
		printf( "Humidity = %d.%d %% Temperature = %d.%d *C (%.1f *F)\n",
			dht11_dat[0], dht11_dat[1], dht11_dat[2], dht11_dat[3], f );
	} else {
		printf( "Data not good, skip\n" );
	}
}

int main( void ) {
	printf( "Raspberry Pi wiringPi DHT11 Temperature test program\n" );

	if ( wiringPiSetup() == -1 )
		exit( 1 );

	while ( 1 ) {
		read_dht11_dat();
		delay( 1000 ); /* wait 1sec to refresh */
	}

	return(0);
}

컴파일

# gcc -Wall -o dht11 dht11.c -lwiringPi -lpthread

실행

디버깅 모드 설정

# export WIRINGPI_DEBUG=TRUE

디버깅 모드 해지

# unset WIRINGPI_DEBUG

실행

# ./dht11
Raspberry Pi wiringPi DHT11 Temperature test program
Data not good, skip
Humidity = 22.0 % Temperature = 23.0 *C (73.4 *F)
Humidity = 22.0 % Temperature = 23.0 *C (73.4 *F)
Data not good, skip
Data not good, skip
Humidity = 22.0 % Temperature = 23.0 *C (73.4 *F)
저작자 표시
신고

Orange PI Zero - pi4j로 PWM 제어

OS/Orange PI 2017.03.25 12:10 Posted by 파란크리스마스

Orange PI Zero - pi4j로 PWM 제어

Orange PI Zero는 하나의 PWM만 지원

배선

Java 소스

import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.OrangePiZeroGpioProvider;
import com.pi4j.wiringpi.Gpio;
import com.pi4j.wiringpi.SoftPwm;

public class SG90PWMMain {

	private static int PIN_NUMBER = 7;

	public static void main(String[] args) throws Exception {
		//
		//GpioFactory.setDefaultProvider(new RaspiGpioProvider(RaspiPinNumberingScheme.BROADCOM_PIN_NUMBERING));
		//GpioFactory.setDefaultProvider(new OrangePiPc2GpioProvider());
		//GpioFactory.setDefaultProvider(new NanoPiNEOAirGpioProvider());
		GpioFactory.setDefaultProvider(new OrangePiZeroGpioProvider());

		// initialize wiringPi library, this is needed for PWM
		Gpio.wiringPiSetup();

		// softPwmCreate(int pin, int value, int range)
		// the range is set like (min=0 ; max=100)
		SoftPwm.softPwmCreate(PIN_NUMBER, 0, 50);
		int counter = 0;
		while (counter < 3) {
			// fade LED to fully ON
			for (int i = 0; i <= 100; i++) {
				// softPwmWrite(int pin, int value)
				// This updates the PWM value on the given pin. The value is
				// checked to be in-range and pins
				// that haven't previously been initialized via softPwmCreate
				// will be silently ignored.
				SoftPwm.softPwmWrite(PIN_NUMBER, i);
				Thread.sleep(25);
			}
			// fade LED to fully OFF
			for (int i = 100; i >= 0; i--) {
				SoftPwm.softPwmWrite(PIN_NUMBER, i);
				Thread.sleep(25);
			}
			counter++;
		}
	}

}

실행

$ sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar SG90PWMMain

실행 영상

저작자 표시
신고

Orange PI Zero GPIO 설치, pi4j

OS/Orange PI 2017.03.25 03:01 Posted by 파란크리스마스

Orange PI Zero GPIO 설치

출처 : WiringOP for Orange pi zero - Beginners - OrangePi - Powered by

현재 pi4j는 Orange PI PC2 지원하지 않아 수정한 jar를 배포합니다.

pi4j-core.jar

$ sudo apt-get install build-essential
$ git clone https://github.com/zhaolei/WiringOP.git -b h3
$ cd WiringOP
$ chmod +x ./build
$ sudo ./build
$ gpio -v
gpio version: 2.20
Copyright (c) 2012-2014 Gordon Henderson
This is free software with ABSOLUTELY NO WARRANTY.
For details type: gpio -warranty

Banana Pro Details:
  Type: Banana Pro, Revision: 1.2, Memory: 1024MB, Maker: LeMaker
orangepi@OrangePizero:~/WiringOP$ gpio readall
 +-----+-----+----------+------+---+-Orange Pi+---+---+------+---------+-----+--+
 | BCM | wPi |   Name   | Mode | V | Physical | V | Mode | Name     | wPi | BCM |
 +-----+-----+----------+------+---+----++----+---+------+----------+-----+-----+
 |     |     |     3.3v |      |   |  1 || 2  |   |      | 5v       |     |     |
 |  12 |   8 |    SDA.0 | ALT5 | 0 |  3 || 4  |   |      | 5V       |     |     |
 |  11 |   9 |    SCL.0 | ALT5 | 0 |  5 || 6  |   |      | 0v       |     |     |
 |   6 |   7 |   GPIO.7 | ALT3 | 0 |  7 || 8  | 0 | ALT3 | TxD3     | 15  | 13  |
 |     |     |       0v |      |   |  9 || 10 | 0 | ALT3 | RxD3     | 16  | 14  |
 |   1 |   0 |     RxD2 | ALT5 | 0 | 11 || 12 | 0 | ALT3 | GPIO.1   | 1   | 110 |
 |   0 |   2 |     TxD2 | ALT5 | 0 | 13 || 14 |   |      | 0v       |     |     |
 |   3 |   3 |     CTS2 | ALT3 | 0 | 15 || 16 | 0 | ALT3 | GPIO.4   | 4   | 68  |
 |     |     |     3.3v |      |   | 17 || 18 | 0 | ALT3 | GPIO.5   | 5   | 71  |
 |  64 |  12 |     MOSI | ALT4 | 0 | 19 || 20 |   |      | 0v       |     |     |
 |  65 |  13 |     MISO | ALT4 | 0 | 21 || 22 | 0 | ALT3 | RTS2     | 6   | 2   |
 |  66 |  14 |     SCLK | ALT4 | 0 | 23 || 24 | 0 | ALT4 | CE0      | 10  | 67  |
 |     |     |       0v |      |   | 25 || 26 | 0 | ALT3 | GPIO.11  | 11  | 21  |
 |  19 |  30 |    SDA.1 | ALT4 | 0 | 27 || 28 | 0 | ALT4 | SCL.1    | 31  | 18  |
 |   7 |  21 |  GPIO.21 | ALT3 | 0 | 29 || 30 |   |      | 0v       |     |     |
 |   8 |  22 |  GPIO.22 | ALT3 | 0 | 31 || 32 | 0 | ALT3 | RTS1     | 26  | 200 |
 |   9 |  23 |  GPIO.23 | ALT3 | 0 | 33 || 34 |   |      | 0v       |     |     |
 |  10 |  24 |  GPIO.24 |  OUT | 0 | 35 || 36 | 0 | ALT3 | CTS1     | 27  | 201 |
 |  20 |  25 |  GPIO.25 |  OUT | 1 | 37 || 38 | 0 | ALT5 | TxD1     | 28  | 198 |
 |     |     |       0v |      |   | 39 || 40 | 0 | ALT5 | RxD1     | 29  | 199 |
 +-----+-----+----------+------+---+----++----+---+------+----------+-----+-----+
 | BCM | wPi |   Name   | Mode | V | Physical | V | Mode | Name     | wPi | BCM |
 +-----+-----+----------+------+---+-Orange Pi+---+------+----------+-----+-----+

C언어 샘플 소스

#include <wiringPi.h>

int main()
{
  wiringPiSetup();
  pinMode(7, OUTPUT);
  while(1) {
    digitalWrite(7,HIGH);
    delay(500);
    digitalWrite(7,LOW);
    delay(500);
  }
  return 0;
}

컴파일

$ gcc -Wall -o blink blink.c -lwiringPi -lpthread

실행

$ sudo ./blink

java 샘플 소스

/*
 * #%L
 * **********************************************************************
 * ORGANIZATION  :  Pi4J
 * PROJECT       :  Pi4J :: Java Examples
 * FILENAME      :  ControlGpioExample.java
 *
 * This file is part of the Pi4J project. More information about
 * this project can be found here:  http://www.pi4j.com/
 * **********************************************************************
 * %%
 * Copyright (C) 2012 - 2016 Pi4J
 * %%
 * This program is free software: you can redistribute it and/or modify
 * it under the terms of the GNU Lesser General Public License as
 * published by the Free Software Foundation, either version 3 of the
 * License, or (at your option) any later version.
 *
 * This program is distributed in the hope that it will be useful,
 * but WITHOUT ANY WARRANTY; without even the implied warranty of
 * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
 * GNU General Lesser Public License for more details.
 *
 * You should have received a copy of the GNU General Lesser Public
 * License along with this program.  If not, see
 * <http://www.gnu.org/licenses/lgpl-3.0.html>.
 * #L%
 */

import com.pi4j.io.gpio.GpioController;
import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.GpioPinDigitalOutput;
import com.pi4j.io.gpio.OrangePiZeroGpioProvider;
import com.pi4j.io.gpio.OrangePiZeroPin;
import com.pi4j.io.gpio.PinState;

/**
 * This example code demonstrates how to perform simple state
 * control of a GPIO pin on the Raspberry Pi.
 *
 * @author Robert Savage
 */
public class ControlGpioExample {

    public static void main(String[] args) throws InterruptedException {

        //GpioFactory.setDefaultProvider(new OrangePiPc2GpioProvider());
        //GpioFactory.setDefaultProvider(new NanoPiNEOAirGpioProvider());
    	GpioFactory.setDefaultProvider(new OrangePiZeroGpioProvider());

        System.out.println("<--Pi4J--> GPIO Control Example ... started.");

        // create gpio controller
        final GpioController gpio = GpioFactory.getInstance();

        // provision gpio pin #01 as an output pin and turn on
        final GpioPinDigitalOutput pin = gpio.provisionDigitalOutputPin(OrangePiZeroPin.GPIO_07, "MyLED", PinState.HIGH);

        // set shutdown state for this pin
        pin.setShutdownOptions(true, PinState.LOW);

        System.out.println("--> GPIO state should be: ON");

        Thread.sleep(5000);

        // turn off gpio pin #01
        pin.low();
        System.out.println("--> GPIO state should be: OFF");

        Thread.sleep(5000);

        // toggle the current state of gpio pin #01 (should turn on)
        pin.toggle();
        System.out.println("--> GPIO state should be: ON");

        Thread.sleep(5000);

        // toggle the current state of gpio pin #01  (should turn off)
        pin.toggle();
        System.out.println("--> GPIO state should be: OFF");

        Thread.sleep(5000);

        // turn on gpio pin #01 for 1 second and then off
        System.out.println("--> GPIO state should be: ON for only 1 second");
        pin.pulse(1000, true); // set second argument to 'true' use a blocking call

        // stop all GPIO activity/threads by shutting down the GPIO controller
        // (this method will forcefully shutdown all GPIO monitoring threads and scheduled tasks)
        gpio.shutdown();

        System.out.println("Exiting ControlGpioExample");
    }
}

실행

$ sudo java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar ControlGpioExample

실행결과

저작자 표시
신고

Orange PI Zero

OS/Orange PI 2017.03.25 02:01 Posted by 파란크리스마스

Orange PI Zero

출처 : 스터디메이크 :: 오렌지파이 제로 보드 간단 사용기
Xunlong Orange Pi Zero

vi 설치

$ sudo apt-get install vim

vnc 설치

출처 : Armbian: Access the Remote Desktop of Orange Pi with VNC

vnc 설치

$ sudo apt-get update && apt-get upgrade
$ sudo apt-get install tightvncserver

vnc 사용자 추가

$ su -
# adduser vnc
Adding user `vnc' ...
Adding new group `vnc' (1001) ...
Adding new user `vnc' (1001) with group `vnc' ...
Creating home directory `/home/vnc' ...
Copying files from `/etc/skel' ...
Enter new UNIX password:
Retype new UNIX password:
passwd: password updated successfully
Changing the user information for vnc
Enter the new value, or press ENTER for the default
        Full Name []: VNCuser
        Room Number []:
        Work Phone []:
        Home Phone []:
        Other []:
Is the information correct? [Y/n]

vnc 사용자 추가

# gpasswd -a vnc sudo
Adding user vnc to group sudo

vnc 서버 실행

# su - vnc
$ vncserver :1

You will require a password to access your desktops.

Password:
Verify:
Would you like to enter a view-only password (y/n)?
*** buffer overflow detected ***: vncpasswd terminated
xauth:  file /home/vnc/.Xauthority does not exist

New 'X' desktop is OrangePizero:1

Creating default startup script /home/vnc/.vnc/xstartup
Starting applications specified in /home/vnc/.vnc/xstartup
Log file is /home/vnc/.vnc/OrangePizero:1.log

Wifi 설정

출처 : 014. Raspberry Pi 라즈베리 파이 - wheezy무선랜 ... - Tsunami - Tistory

$ cd /etc/ifplugd/action.d/
$ sudo mv ifupdown ifupdown.bk
$ sudo cp /etc/wpa_supplicant/ifupdown.sh ./ifupdown

암비안 와이파이 설정

출처 : 오렌지파이 제로 무선인터넷 설정 1.2 암비안 와이파이 설정

$ sudo nmtui

SD 확장

SD 확장전 용량확인

$ sudo fdisk /dev/mmcblk0
Filesystem      Size  Used Avail Use% Mounted on
/dev/root       1.6G  1.2G  349M  78% /
devtmpfs        168M     0  168M   0% /dev
tmpfs           224M     0  224M   0% /dev/shm
tmpfs           224M  8.5M  216M   4% /run
tmpfs           5.0M  4.0K  5.0M   1% /run/lock
tmpfs           224M     0  224M   0% /sys/fs/cgroup
tmpfs           224M  4.0K  224M   1% /tmp
/dev/mmcblk0p1   63M  4.6M   59M   8% /media/boot
tmpfs            45M     0   45M   0% /run/user/107
tmpfs            45M     0   45M   0% /run/user/1000

SD FDisk

orangepi@OrangePizero:~$ sudo fdisk /dev/mmcblk0

Welcome to fdisk (util-linux 2.25.2).
Changes will remain in memory only, until you decide to write them.
Be careful before using the write command.


Command (m for help): p
Disk /dev/mmcblk0: 7.4 GiB, 7948206080 bytes, 15523840 sectors
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x000b04ea

Device         Boot  Start     End Sectors  Size Id Type
/dev/mmcblk0p1       40960  172031  131072   64M  b W95 FAT32
/dev/mmcblk0p2      172032 3514367 3342336  1.6G 83 Linux


Command (m for help): d
Partition number (1,2, default 2): 2

Partition 2 has been deleted.

Command (m for help): n
Partition type
   p   primary (1 primary, 0 extended, 3 free)
   e   extended (container for logical partitions)
Select (default p): p
Partition number (2-4, default 2): 2
First sector (2048-15523839, default 2048): 172032
Last sector, +sectors or +size{K,M,G,T,P} (172032-15523839, default 15523839):

Created a new partition 2 of type 'Linux' and of size 7.3 GiB.

Command (m for help): w
The partition table has been altered.
Calling ioctl() to re-read partition table.
Re-reading the partition table failed.: Device or resource busy

The kernel still uses the old table. The new table will be used at the next reboot or after you run partprobe(8) or kpartx(8).

orangepi@OrangePizero:~$ sudo shutdown -r now

SD 확장

$ sudo resize2fs /dev/mmcblk0p2
resize2fs 1.42.12 (29-Aug-2014)
Filesystem at /dev/mmcblk0p2 is mounted on /; on-line resizing required
old_desc_blocks = 1, new_desc_blocks = 1
The filesystem on /dev/mmcblk0p2 is now 1918976 (4k) blocks long.

SD 확장 확인

$ df -h
Filesystem      Size  Used Avail Use% Mounted on
/dev/root       7.3G  1.2G  5.8G  17% /
devtmpfs        168M     0  168M   0% /dev
tmpfs           224M     0  224M   0% /dev/shm
tmpfs           224M  8.5M  216M   4% /run
tmpfs           5.0M  4.0K  5.0M   1% /run/lock
tmpfs           224M     0  224M   0% /sys/fs/cgroup
tmpfs           224M  4.0K  224M   1% /tmp
/dev/mmcblk0p1   63M  4.6M   59M   8% /media/boot
tmpfs            45M     0   45M   0% /run/user/107
tmpfs            45M     0   45M   0% /run/user/1000

JDK 설치

$ sudo apt install -t jessie-backports openjdk-8-jre openjdk-8-jre-headless openjdk-8-jdk openjdk-8-jdk-headless ca-certificates-java

JAVA_HOME 환경변수 추가

$ sudo vi /etc/profile

내용 추가 export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-armhf

export JAVA_HOME=/usr/lib/jvm/java-8-openjdk-armhf
저작자 표시
신고

NanoPi NEO Air - pi4j로 PWM 제어

OS/NanoPi 2017.03.22 23:08 Posted by 파란크리스마스

NanoPi NEO Air - pi4j로 PWM 제어

NanoPi NEO Air는 하나의 PWM만 지원

배선

Java 소스

import com.pi4j.io.gpio.GpioFactory;
import com.pi4j.io.gpio.NanoPiNEOAirGpioProvider;
import com.pi4j.wiringpi.Gpio;
import com.pi4j.wiringpi.SoftPwm;

public class SG90PWMMain {

	private static int PIN_NUMBER = 1;

	public static void main(String[] args) throws Exception {
		//
		//GpioFactory.setDefaultProvider(new RaspiGpioProvider(RaspiPinNumberingScheme.BROADCOM_PIN_NUMBERING));
		//GpioFactory.setDefaultProvider(new OrangePiPc2GpioProvider());
		GpioFactory.setDefaultProvider(new NanoPiNEOAirGpioProvider());

		// initialize wiringPi library, this is needed for PWM
		Gpio.wiringPiSetup();

		// softPwmCreate(int pin, int value, int range)
		// the range is set like (min=0 ; max=100)
		SoftPwm.softPwmCreate(PIN_NUMBER, 0, 50);
		int counter = 0;
		while (counter < 3) {
			// fade LED to fully ON
			for (int i = 0; i <= 100; i++) {
				// softPwmWrite(int pin, int value)
				// This updates the PWM value on the given pin. The value is
				// checked to be in-range and pins
				// that haven't previously been initialized via softPwmCreate
				// will be silently ignored.
				SoftPwm.softPwmWrite(PIN_NUMBER, i);
				Thread.sleep(25);
			}
			// fade LED to fully OFF
			for (int i = 100; i >= 0; i--) {
				SoftPwm.softPwmWrite(PIN_NUMBER, i);
				Thread.sleep(25);
			}
			counter++;
		}
	}

}

실행

# java -cp .:pi4j-core.jar:pi4j-gpio-extension.jar SG90PWMMain

실행 영상

저작자 표시
신고




티스토리 툴바
